Video Off Method

This determines the manner in which the monitor is blanked.
V/H SYNC+Blank
Blank Screen
DPMS Support

MODEM Use IRQ

This determines the IRQ in which the MODEM can use.
The choice: 3, 4, 5, 7, 9, 10, 11, NA.
Soft-Off by PWRBTN
Pressing the power button for more than 4 seconds forces the system
to enter the Soft-Off state when the system has "hung."
The choice: Delay 4 Sec, Instant-Off.
State After Power Failure
State after power is re-applied
The choice: On, Off.
Wake Up Event
Wake Up events are I/O events whose occurrence can prevent the system
from entering a power saving mode or can awaken the system from such a
mode. In effect, the system remains alert for anything which occurs to a
device which is configured as On, even when the system is in a power down
mode.
VGA
When On, you can set the VGA awakens the system.
LPT & COM
When On of LPT & COM, any activity from one of the listed system peripheral
devices or IRQs wakes up the system.
This selection will cause the system to turn off the
vertical and horizontal synchronization ports and
write blanks to the video buffer.
This option only writes blanks to the video
buffer.
Select this option if your monitor supports the
Display Power Management Signaling (DPMS)
standard of the Video Electronics Standards to
select video power management values.
47
