2.5 SCSI Port A/B Terminator Selection Setting

Two SCSI terminators Port A and Port B are supported, JP5 is

for Terminator Port A and JP6 is for Terminator Port B

• JP5, JP6 : Terminator Enable/Disable Setting

JP5, JP6

2-3

1-2

DESCRIPTION

Enable

Disable
