3.18 Ultra-160 68pin SCSI Connector
Two 68pin SCSI connectors are described as below.
• CN24: Port A, CN25: Port B
CN24/CN25 : SCSI pin assignment
PIN NO.
DESCRIPTION
1
+SD12
2
+SD13
3
+SD14
4
+SD15
5
+SDP1
6
+SD0
7
+SD1
8
+SD2
9
+SD3
10
+SD4
11
+SD5
12
+SD6
13
+SD7
14
+SDP0
15
GND
16
DIFF SENSE
17
VCC
18
VCC
19
NC
20
GND
21
+SATN
22
GND
23
+SBSY
24
+SACK
25
+SRST
26
+SMSG
27
+SSEL
28
+SCD
29
+SREQ
30
+SIO
31
+SD8
32
+SD9
33
+SD10
34
+SD11
PIN NO.
DESCRIPTION
35
-SD12
36
-SD13
37
-SD14
38
-SD15
39
-SDP1
40
-SD0
41
-SD1
42
-SD2
43
-SD3
44
-SD4
45
-SD5
46
-SD6
47
-SD7
48
-SDP0
49
GND
50
NC
51
VCC
52
VCC
53
NC
54
GND
55
-SATN
56
GND
57
-SBSY
58
-SACK
59
-SRST
60
-SMSG
61
-SSEL
62
-SCD
63
-SREQ
64
-SIO
65
-SD8
66
-SD9
67
-SD10
68
-SD11
24
