ACTIVE Cube 401 (75.0 kW to 132.0 kW)

Rb2
L1
Threaded bolt M8x20
Note: Optional, the inverters in this size can be purchased without brake chopper and are then not provided with
the terminal Rb2 for a brake resistor connection.
34
34
V W
ZK+
ZK-
L2 L3
10 Nm
88.5 lb-i n
Motor power connection
U
W
U
M
3~
Star connection
Connection of a brake resistor with temperature switch
ZK+
ZK+
T1
Mains power connection
L1
L2 L3 PE
3ph / 400V AC
W U
Delta connection
Rb2
b
Rb2
T 2
L2 L3
W
