Active Cube 401 (37.0 To 65.0 Kw) - BONFIGLIOLI active cube 201 Quick Start Manual

3.5

ACTIVE Cube 401 (37.0 to 65.0 kW)

X1
X2
Use the terminals R and R
b1
Note: Optional, the inverters in this size can be purchased without brake chopper and are then not provided with
the terminal Rb2 for a brake resistor connection.
09/08
09/08
Mains power connection, X1
X1
-
+
L1 L2 L3
L1 L2 L3
3ph / 400V AC
Motor power connection, X2
U
V W
U V W
Delta connection
Star connection
to connect a brake resistor.
b2
PE
X2
U V W
Rb1
M
3~
8 Nm
70.8 lb-in
Rb2
8 Nm
70.8 lb-in
33
33
