How to Do Customized Output Resolution

How to Do Customized Output Resolution
Push the [MENU/EFFECT] button to enter the menu items, turn the knob
and choose [OUTPUT], push the knob to confirm. Turn the knob, choose
<OUTPUT FORMAT>, push the knob to confirm and go into the output
format menus, OLED module show as following:
STANDARD--Standard resolution.
CUSTOM--Used defined resolution setting.
Push the knob and go into <CUSTOM> menu:
Turn knob on each digital position, and change the value of the digital by
the digital buttons on the front panel. For example, input 1536 as following:
After the digital, push knob will add *, means before the * is the horizontal
size. Same operation for vertical size, for example input1536 as following:
After the digital, push the knob will add @, means before the @ is the
vertical size, and after the @ is the refresh rate. Only digital 50 or digital 60
supports for the refresh rate. Use the digital buttons to finish the settings, .
For example to input refresh rate 60.
VSP 9516S
CUSTOM:
->1920×1080@60
CUSTOM:
*1536×
CUSTOM:
*1536×1536@
User Manual 89
