PAK 200
Type Torch: PCH-200
Type Plasma Gas: Ar-35H2
Output
Thickness Tip Volts
Inches mm (Cat. No.) (VDC)
0.250 6.4 32-1322 130
0.500 12.7 32-1322 135
0.750 19.1 32-1322 135
1.000 25.4 32-1322 140
0.500 12.7 32-1323 145
0.750 19.1 32-1323 150
OPERATION
Amper- Speed (Per
age Minute) Standoff
(Amps) Inches Meters Inches
120 100 2.5 0.25
120 60 1.5 0.25
120 30 0.8 0.25
120 20 0.5 0.25
200 110 2.8 0.3
200 50 1.3 0.4
Type Material: Aluminum
Type Secondary Gas: Nitrogen
Plasma Gas
Press Sec Gas Press
mm psi bar psi bar
6.4 65 4.5 60 4.1
6.4 65 4.5 60 4.1
6.4 65 4.5 60 4.1
6.4 65 4.5 60 4.1
7.6 70 4.8 60 4.1
10.2 70 4.8 60 4.1
4-12
Total Flow (SCFH) Pierce Height
Plasma Secondary Inches mm
75 340 0.25 6.4
75 340 0.38 9.7
75 340 0.38 9.7
75 340 N/R N/R
82 340 0.40 10.2
82 340 0.45 11.4
