PAK 200
2.06 Power Supply Specifications & Electrical Requirements
Max OCV (U
Max Output Current
Output Voltage
Duty Cycle Rating
Operating range
Power Factor
Cooling
Input
Voltage
(Volts)
208
230
400
400 (CE)
460
Extra Hard Usage Type SO, SOW, SOO, SOOW, ST, STW, STO, STOW, STOO, STOOW
1
Fuse and wire sizes are for reference only. The installation must conform to national and local codes
for the type and method of wire being used.
SPECIFICATIONS
PAK 200 Power Supply Specifications
) 380 vdc
0
200 Amps
160 vdc
100% @ 200A @ 160V (32 kW)
14°F to 122°F (-10°C to + 50°C)
0.70 @ 200 ADC Output
Forced Air (Class F)
PAK-200 Power Supply
Power Input
Freq. 3-Ph
(Hz) (kVA)
60 47
60 49
50 54
50 54
60 59
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electrical Code
Extra Hard Usage Type G, G-GC, W
2
Current Suggested Sizes (See Note)
3-Ph Fuse (Amps)
(Amps) 3-Ph
130 160
125 150
77 100
77 100
75 90
CAUTION
2-2
Wire (AWG)
3-Ph
#2
2
#2
2
#4
1
#4
1
#4
1
Manual 0-5057
