Setting Terminal Parameters - H3C S3100V2-52TP Installation Manual

Connect the RJ-45 connector to the console port of the switch.
Step2
WARNING!
Identify the mark on the console port to ensure that you are connecting to the correct port.
•
When connecting a PC to a powered-on switch, connect the DB-9 connector of the console cable to the
•
PC before connecting the RJ-45 connector to the switch.
• When disconnecting a PC from a powered-on switch, disconnect the DB-9 connector of the console
cable from the PC after disconnecting the RJ-45 connector from the switch.

Setting terminal parameters

When setting up the configuration environment through the console port, the terminal or PC can use the
terminal emulation program to communicate with the switch. You can run the HyperTerminal of the
Windows operating system to connect to other PCs, network devices, and Telnet sites. For more
information about the HyperTerminal, see the HyperTerminal Help documentation in Help and Support
Center on the PC running the Windows operating system.
In the following configuration procedure, Windows XP HyperTerminal is used to communicate with the
switch.
Start the PC and run the terminal emulation program.
1.
Set terminal parameters as follows:
2.
Bits per second: 9,600
•
Data bits: 8
•
• Parity: None
Stop bits: 1
•
Flow control: None
•
Emulation: VT100
•
Follow these steps to set terminal parameters:
Select Start > All Programs > Accessories > Communications > HyperTerminal to enter the
Step1
HyperTerminal window. The Connection Description dialog box appears, as shown below.
