Servo Reverse "REVERSE"

This function reverses the direction of operation of the servos related to transmitter
steering, throttle, and channel 3 /4 operation.
Display to "REVERSE" screen by the following method:
(HOME screen)
Servo Reverse Function Setting
(Preparation)
- Select the channel to be set by the (JOG) button up or down
operation.
1
(Servo reverse setting)
Use the (+) or (-) button to reverse the servo
operation direction.
NOR/REV can also be set by (JOG) button left or right oper-
ation
(Each channel can be set similarly.)
2
When ending, move the cursor to [RT] by the (JOG) button,
and return to the MENU1 screen by pressing the (JOG) but-
ton.
44
However, when the position set by trim or subtrim shifts from
the center, the center becomes the opposite side.
(MENU 2 screen)
Pre
Pre
Servo Reverse "REV"
(MENU 1 screen)
Select
"REVERSE"
(All channel)
(REVERSE screen)
Pre
Pre
Setting item
STR :Steering (1st channel)
THR :Throttle (2nd channel)
CH3 :3rd channel
CH4 :4th channel
Move the cursor to "STR, THR,
CH3 and CH4" with the (JOG)
button.
Select button
- Select with the (+) or (-) but-
tons.
