FUTABA 4pls Instruction Manual page 96

Timer screen
Time display
Minute display (m)
Second display (s)
1/100 second display
Racing timer type selection
(Preparation)
Assign the "TIMER" switch using the function select switch
(p.65).
1
(Racing timer type selection)
Select the setting item "TYPE" by the (JOG) button. Use the
(+) or (-) button and set the racing timer type.
Timer selection (TYPE)
UP
DOWN
LAP
2
When ending, return to the MENU2 screen by pressing the
(JOG) button.
96
: Up timer
: Down timer
: Lap timer
Timer Function "TIMER"
Timer selection
First, select the type of timer
at the "TYPE" item. The setup
screen varies depending on the
type of timer. This figure shows
the UP TIMER setup screen.
Status display
RST :Reset state
RDY :Throttle trigger operation wait
RUN :Timer running
STP : Timer stopped
Setup item selection
- Select by the (JOG) button.
Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
