Throttle Mode Check

The throttle servo travel can be set to 5:5 or 7:3 for throttle trigger operation as required
by the throttle mode function (page 80).
F5/B5 or F7/B3

Trims Initial Set-Up

- Steering trim (DT1) check
On the initial set-up, steering trim is assigned to the DT1 trim lever above the steering
wheel. Operate the lever and make sure the marker moves on the ST graph. If default
has been changed, test steering trim in its new location. After checking the trim, set the
trim display to the center (N) position.
- Throttle trim (DT2) check
On the initial set-up, throttle trim is assigned to the DT2 trim lever on the left side of
the steering wheel. Operate the lever and make sure the marker moves on the TH graph.
If the default has been changed, test the throttle trim in its new location. After checking
the trim, set the trim display to the center (N) position.
Throttle trim (DT2)
F5/B5
5 : 5
Forward side Brake side
Steering trim (DT1)
F7/B3
7 : 3
Forward side Brake side
Steering trim
Throttle trim
