Model Name "MDL NAME"

This function allows you to assign a ten character name to each model memory and
user name.
Display to "MDL NAME" screen by the following method:
(MENU 2 screen)
(HOME screen)
Pre
When (JOG) button left or right operation is performed from both the left
and right ends of the character list, the page (all 3 pages) is changed
and the character set is selected.
(KATAKANA of the 3rd page is displayed when "KANA" is set by the
"SYSTEM" function "MENU".)
Setting the model name and user name
1
(Move the cursor to the character you want to change.)
Select the model name character you want to set or change
by moving the cursor by the (+) or (-) button. The selected
character blinks.
2
(Selecting the character to be used)
Select the character to be used from the character list at un-
der side of the screen by the (JOG) button up, down, left, or
right operation. The selected character blinks. After selecting
the character to be used, press the (JOG) button. The char-
acter is entered and the model name or user name character
row moves to the right.
Also move the cursor to "RESET" by the (JOG) button up,
down, left, or right operation, and press the buttons for about
1 second. A beeping sound is generated and the model
name is initialized to the factory setting.
3
When ending, move the cursor to [RT] by the (JOG) button,
and return to the MENU1 screen by pressing the (JOG) but-
ton.
(MENU 1 screen)
Select
Pre
"MDL NAME"
Pre
Model Name "MOE NAME"
(MDL NAME screen)
Pre
cursor position [RT]
Move the cursor to the char-
acter you want to change by
(+) or (-) button.
Select the character by
(JOG) button.
Move the cursor to "RE-
SET" by the (JOG) button
up or down operation.
Model name
User name
Character
