Exponential Adjustment "EXP"

This function is used to change the sensitivity of the servo around the neutral position.
Display to "EXP" screen by the following method:
(HOME screen)
Pre
STR (Steering EXP)
This function is used to change the sensitivity of the
steering servo and around the neutral position. It has
no effect on the maximum servo travel.
Racers Tip
When the setting is not determined, or the
characteristics of the model are unknown,
start with 0%. (When EXP is set to 0%, servo
movement is linear.)
Steering EXP adjustment
(Preparation)
- On the EXP screen,
button.
1
When you want to quicken steering operation,
use the (+) button to adjust the + side. When
you want to make steering operation milder,
use the (-) button to adjust the - side.
2
When ending, return to the MENU1 screen by pressing the
(JOG) button.
(MENU 2 screen) (MENU 1 screen)
Pre
Select the setting item "STR" by the (JOG)
Exponential Adjustment "EXP"
(Steering/ Throttle system)
Pre
Select "EXP"
Pre
Setting item
STR :Steering
FWD :Throttle forward side
BRK :Throttle brake/ reverse side
Quick
(Positive side)
Wheel operation
Adjustment range
-100~0~+100
Adjust button
- Adjust with the (+) and (-) but-
tons.
- Return to the initial value "0" by
pressing the (+) and (-) buttons
simultaneously for about 1 sec-
ond.
Vertical cursor moves in step
with steering wheel operation.
(EXP screen)
Mild
(Negative side)
Wheel operation
51
