Receiver Type Change & How To Link - FUTABA 4pls Instruction Manual

If the receiver used and the RX type settings are different, change the RX type using
the "RX MODE" function. Which RX type is set can be checked at the HOME screen.
T-FHSS Normal speed
T-FH (NORM)
Receiver type change & How to Link
are linked and the transmitter ID No. is memorized at the receiver so that signals from
other transmitters will not be received. The telemetry type T-FHSS also simultaneously
memorizes the ID No. of the receiver at the transmitter so that data from other receivers
will not be received.
The RX type setting and transmitter and
receiver linking methods are described
the edit buttons used.
1
Set the transmitter power switch to DISP. Se-
lect "RX Setting" by (JOG) button up or down
operation, and display the "RX MODE" screen
by pressing the (JOG) button.
2
Move the cursor to "TYPE: ----" by (JOG) but-
ton up or down operation, and select the RX
type with the (+) button or (-) button.
When the (JOG) button is pressed for approximately 1 second, an electronic sound is
generated and setting ends.
30
T-FHSS High speed S-FHSS Normal speed
T-FH (HIGH)
Select TYPE with
the (+) or (-) but-
ton.
Select RX type with the (+)
or (-) button.
S-FHSS High speed
S-FH (NORM) S-FH (HIGH)
(-) button
Select "RX MODE"
by (JOG) button.
Press the (JOG) buttons
simultaneously for approxi-
mately 1 second.
FHSS
(+) button
(JOG) button
Pu h
Pu h
