Exploded View (4x4, 6x6), Cont.
Ref. Qty.
1
Asm., 4x4 Transmission
1.
1
Nut
2.
1
Shift Drum Bellcrank
3.
5
Cover Screws
4.
1
Sector Cover
6.
1
O-ring
7.
1
Detent Pawl
8.
1
Compression Spring
9.
1
Shift Shaft
10.
1
31T Sector Gear
11.
2
Hollow Hex Plug
12.
2
Triple Lip Seal
13.
1
Gearcase, Main
14.
1
Vent Tube
15.
1
O-Ring
16.
1
Shift Drum
17.
1
External Retaining Ring
18.
1
6-Pin Switch
19.
1
O-ring
20.
1
Detent Star
21.
1
Lockout Disc
22.
1
16T Sector Gear
23.
2
Lock Nut
24.
4
Dowel Pin
25.
4
Ball Bearing
26.
1
Thrust Washer
27.
1
Vent Plug Cap
28.
1
Output Shaft
29.
1
Shim
30.
1
Thrust Button
31.
1
Shim
32.
1
Output Cover
33.
15
Screw
34.
1
Plain Bearing
Description
Ref.
Qty.
35.
1
22T Sprocket
36.
1
19T Sprocket
37.
1
Silent Chain
38.
1
Front Main Output Shaft
39.
1
Gear Set - 10T / 31T
40.
1
Ball Bearing
41.
1
Spacer
42.
1
Retaining Ring
43.
1
Bearing Center Drive Cover
44.
4
Torx Screws
45.
1
56T Mid Output Helical Gear (6x6: 60T Gear)
46.
4
Ball Bearing
47.
1
Reverse Shaft
48.
1
Needle Cage Bearing
49.
1
24T 6 Face Sprocket
50.
1
Washer
51.
2
External Retaining Ring
52.
4
6 Face Engagement Dog
53.
2
Wave Spring
54.
1
Washer
55.
2
Needle Cage Bearing
56.
1
28T 6 Face Gear (6x6: 23T Gear)
57.
1
51T Mid Output Helical Gear (6x6: 47T Gear)
58.
1
Shift Shaft Rail
59.
2
Shift Fork w/Pin
61.
1
Silent Chain
62.
1
Input Shaft Assy.
63.
1
LH Main Cover
64.
1
Dual Lip Seal
65.
1
Transmission Mount Bracket
66.
2
Hex Screw
67.
1
33T 6 Face Gear
68.
1
Washer
69.
1
Label
TRANSMISSION
Description
8.17
