sensors connected to the analogue inputs. The regulator makes the same PVED-CL compatible to both 12
and 24 Volt batteries. For more information, see

Actuator Position Sensor

The actuator sensor serves the purpose to allow external closed loop position control, for example soft
stop or variable steering sensitivity depending on cylinder position.
For added safety the PVED-CL provides connectivity of a second sensor inputs at the same interface type.
When position sensors are mounted on the steering actuator, the signal range must be at least 5 to 10%
larger than maximum physical movement of the actuator.
The PVED-CL incorporates a printed circuit board (PCB), LVDT sensor and a solenoid operated hydraulic
H-bridge. The PCB provides connectivity to CAN and analogue signals by two 4-pin connectors each
1
colored differently to distinguish CAN and power supply from cables with analog control signals. The
gray connector is dedicated for CAN and electric power supply and the black for connecting analogue
devices to the PVED.
MMI
Display, Buttons e.g. to select program,
Display Info, Status, Diagnostic CAN
Configuration & Adjustment
and PVED-CL Communication Protocol
Steering wheel sensor
(SASA) CAN
Mapping a Steering
Device
Control principle: Control principle:
Closed loop Open loop
Vehicle Speed
Dependent Sensitivity
Actuator Dependent
Sensitivity
Anti-Drift
(knob position control)
Soft End Stop
Anti Jerk
Fixed Ramps
Anti Jerk
Speed Dependent Times
Technical Data
Vehicle speed signal (J1939 CAN)
Mapping a Steering Device
and PVED-CL Communication
Protocol
High Priority
steering device
Analogue or CAN
Mapping a Steering
Device
Control principle: Control principle:
Closed loop Open loop
Vehicle Speed
Dependent Sensitivity
Actuator Dependent
Sensitivity
Soft End Stop
Anti Jerk
Fixed Ramps
Anti Jerk
Speed Dependent Times
on page 22.
