Optional Swivel Belt Clip - Icom IC-F4062S Sales Handbook

2-8-2
SWIVEL BELT CLIP
MB-93 contents
a.Belt clip............................................................... 1
b.Base clip ............................................................ 1
To attach
a.Release the battery pack if it is attached.
b.Slide the base clip in the direction of the arrow until
the base clip is locked and makes a 'click' sound.
a. Clip the belt clip to a part of your belt. And insert the
transceiver into the belt clip until the base clip
inserted fully into the groove.
a. Once the transceiver is locked in place, it swivels as
illustrated below.
Once the transceiver is locked in place,
it will swivel 360 degrees.

Optional Swivel Belt Clip

To detach
Qty. a.Turn the transceiver upside down in the direction of
the arrow and pull out from the belt clip.
•
•
CAUTION!
HOLD THE TRANSCEIVER TIGHTLY, WHEN HANGING OR
DETACHING THE TRANSCEIVER FROM THE BELT CLIP.
Otherwise the transceiver may not be attached to the
holder or swivel properly if the transceiver is accidentally
dropped and the base clip is scratched or damaged.
Release the battery pack if it is attached.
Pinch the clip ( ), and slide the base clip in the
direction of the arrow ( ).
17
