3.3 Download and Change the Configuration
Now that Anybus Configuration Manager has an active connection to the X-gateway, the interface con-
figurations from the unit can be uploaded, viewed and modified.
1. Click Upload configuration from X-gateway.
2. After the current configuration has loaded, it can then
be edited as required.
3. After making changes to the configuration, select Online>>Download Configuration. The
new configuration is saved to the X-gateway.
To check that the new configuration was saved successfully, the configuration can be uploaded again
from the X-gateway.
For further information on all of the available settings for each network interface, please see the online
help in Anybus Configuration Manager.
Anybus X-gateway User Manaul
Anybus Configuration Manager 18
Doc: HMSI-27-262, Rev: 2.10
