Document History; Revision List; Conventions & Terminology; Support - HMS Anybus X-Gateway Series User Manual

P. About This Document
This document provides an understanding of the functionality shared by the various versions of the
Anybus X-gateway. It does not, however, cover any network-specific features. These are instead covered
in separate documents known as Interface Addendums.
The reader is expected to be familiar with communication systems in general, and industrial networking
systems in particular. For more information, documentation etc., please see www.anybus.com.
P.1 Document History
P.1.1 Revision List
Revision Date
1.00 2004-04-02 PeP
1.01 2005-02-14 PaL
1.02 2005-09-01 PaL
1.10 2007-06-25 PeP
1.11 2007-11-23 PeP
1.12 2009-05-08 KeL
1.13 2011-02-07 KaD
1.20 2013-01-21 SDa
2.00 May 2014
2.10 August
2014
P.2 Conventions & Terminology
The following conventions are used throughout this manual:
• Numbered lists provide sequential steps
• Bulleted lists provide information, not procedural steps
• The terms 'gateway' and 'X-gateway' refer to the Anybus X-gateway
• Hexadecimal values are written in the format NNNNh, where NNNN is the hexadecimal value.
• All measurements in this document have a tolerance of ±0.25mm unless otherwise stated
• 16/32 bit values are generally stored in Motorola (big endian) format unless otherwise stated.
• The term "byte" always refers to a string of 8 bits
P.3 Support
For contact information and support, please refer to the contact and support pages at:
www.anybus.com/support
Anybus X-gateway User Manaul
Author(s) Chapter(s) Description
All First release
5, 7 and 8 Reset bit, offset bits main menu
6, 7 and 8 Changed default setting of Control/Status and Live List
All Major rewrite
2 Minor update
Preface Minor update
and 2
3, B Minor update
1, 2 Minor corrections. New document template.
SDa Several New hardware and Anybus Configuration Manager
SDa 1, 4, B Updates for UL approval
Preface
Doc: HMSI-27-262, Rev: 2.10
