2.3 Controlling the Gateway from the Network

2.3.1 Control Word

It is possible to control certain aspects of the gateway from the network by setting the corresponding
bits in the Control Word.
This functionality is disabled by default, but can be enabled separately for each network interface
through the Gateway Config Interface. Note that if enabled, certain actions may be required in order for
the gateway to start exchanging data.
Control Word Contents:
b15 b14
(MSB)
• Master Mode
These bits specify the current operation mode of the on-board master from the other network
(these bits are not available on the master/scanner side).
The exact definition of these bits depend on the network in question, however common for all
networks is that if the Control Word has been enabled, it is required to specify a value for these
bits in order for the gateway to start exchanging data.
See also...
- 3-16 "Anybus Configuration Manager"
- Interface addendum for the on board master/scanner.
• Reset
This bit is used to reset the gateway.
1: Restart the gateway and re-initialize both network interfaces.
0: (no action)
See also...
• 2-11 "Status & Diagnostics"
• 3-16 "Anybus Configuration Manager"

2.3.2 Network Specific Controls

Some interfaces may provide additional methods of controlling the gateway from the network. For fur-
ther information, consult the separate interface addendums for your product.
1. Master configurations only.
Anybus X-gateway User Manaul
b13 b12 b11 b10 b9
1
b8 b7 b6 b5 b4
Reset
Basic Operation 13
b3 b2 b1 b0
Master Mode
(LSB)
