2.2.2 Live List (Master Configurations Only)

Optionally, the gateway provides a list of the active status of the slaves associated with the on board mas-
ter. The list is assembled by the master interface and forwarded to the other network each gateway cycle.
This functionality is disabled by default, but can be enabled via the Gateway Config Interface.
Live List Contents:
Offset
0
1
2
3
4
5
6
7
• Bit Set (1)
Slave active.
(The exact interpretation of this bit is network specific. Consult the separate interface addendum
for the master network interface)
• Bit Cleared (0)
Slave not active.
(The exact interpretation of this bit is network specific. Consult the separate interface addendum
for the master network interface)
Note 1: Although certain masters may support more than 64 slaves, only node number 1... 64 will be
represented in the Live List.
Note 2: The EtherNet/IP Scanner Interface does not feature a Live List. Instead, it is possible to rep-
resent statistics about configured, active, and erroneous connections.
See also...
• 3-16 "Anybus Configuration Manager"

2.2.3 Network Specific Status

Some network interfaces may provide additional registers or status lists. For further information, consult
the separate interface addendums for your product.
Anybus X-gateway User Manaul
Bit 0 Bit 1 Bit 2
Slave 0 Slave 1 Slave 2
Slave 8 Slave 9 Slave 10
Slave 16 Slave 17 Slave 18
Slave 24 Slave 25 Slave 26
Slave 32 Slave 33 Slave 34
Slave 40 Slave 41 Slave 42
Slave 48 Slave 49 Slave 50
Slave 56 Slave 57 Slave 58
Bit 3 Bit 4 Bit 5
Slave 3 Slave 4 Slave 5
Slave 11 Slave 12 Slave 13
Slave 19 Slave 20 Slave 21
Slave 27 Slave 28 Slave 29
Slave 35 Slave 36 Slave 37
Slave 43 Slave 44 Slave 45
Slave 51 Slave 52 Slave 53
Slave 59 Slave 60 Slave 61
Basic Operation 12
Bit 6 Bit 7
Slave 6 Slave 7
Slave 14 Slave 15
Slave 22 Slave 23
Slave 30 Slave 31
Slave 38 Slave 39
Slave 46 Slave 47
Slave 54 Slave 55
Slave 62 Slave 63
