11.

Installing the grille. Position the grille so that it covers the baffle of the speaker. Six

small magnets secure the grille in place.

Speaker Grille

Figure 38.

Installing the Grille

NOTE: Specific test points can be used to troubleshoot speaker system problems.

Should problems be encountered, please see

on the next page.

Troubleshooting: Signal Test Points

SF 3C LP and SF 3CT LP User Guide • Installation
