14.
If required, attach a secondary support line.
a.
Connect a secondary support line to the support loop on the back of the speaker
enclosure, as shown here.
Figure 24.
Connecting a Secondary Support Line
ATTENTION:
•
Do not allow any slack in the secondary support line.
•
Ne laissez pas de mou au niveau du filin de sécurité secondaire.
b.
Replace the adjacent ceiling tile that was removed in
15.
Repeat steps 4 through 14 for each speaker being installed.
16.
Attach the speaker assembly to the back can enclosure.
a.
Connect the speaker wires from the back can enclosure to the speaker assembly.
Figure 25.
Connecting Speaker Wires to the Speaker Assembly
Anchor end to suitable
secure points within the
solid and permanent
building structure.
SF 3C LP and SF 3CT LP User Guide • Installation
step 7b
on page 14.
20
