NOTE: The cable conduit access plate can be positioned in one of two ways
depending on installer preference. Flip the plate to the desired position with the
wire openings either on the side or on the top of the speaker enclosure before
tightening the screws.
As examples:
•
The side access wire opening can be useful in low profile installations.
•
The top access wire opening can be more convenient to use.
12.
Tighten the cable clamp if it was used.
13.
Mount the speaker back can enclosure.
a.
Insert the speaker through the bottom of the hole in the ceiling tile that was cut in
step 6
on page 13 with the wires out of the way.
Figure 21.
Inserting the Speaker Back Can
b.
Clamp the speaker back can to the C-ring by using a Phillips screwdriver to tighten
the three locking arms to the C-ring.
OR
SF 3C LP and SF 3CT LP User Guide • Installation
18
