10.

Install the grille. Position the grille so that it covers the baffle of the speaker. Six small

magnets secure the grille in place.

Speaker Grille

Figure 12.

Installing the grille

NOTE: Specific test points can be used to troubleshoot speaker system problems.

Should problems be encountered, please see

on page 31.

Troubleshooting: Signal Test Points

SF 3C LP and SF 3CT LP User Guide • Installation
