326 C 12: V
HAPTER IRTUAL
VRRP parameters for
Router 2

Enable VRRP

VRRP and Other
Networking
Operations
R R P
OUTER EDUNDANCY ROTOCOL
Virtual
VLAN Router
Index IP Interface Type
2 10.1.0.253 Backup 1
3 10.1.4.253 Backup 2
4 10.1.4.253 Primary
5 10.1.4.253 Primary
6 150.100.0.8 Backup 5
You must explicitly turn virtual routing on for each virtual router in order
to enable your virtual router to become an active component of VRRP on
your network. Use
the IP VRRP Mode form in the Web Management console to enable VRRP.
If you want to redefine a VLAN that is being used for a virtual router, you
must remove the virtual router, then remove the IP interface used by the
virtual router, then finally remove the VLAN.
Read this section for information about how VRRP interacts with other
networking functions, including:
Spanning Tree Protocol (STP)
Dynamic routing protocols:
Routing Information Protocol (RIP)
Routing Information Protocol version 2 (RIP-2)
Open Shortest Path First (OSPF)
IP Multicast
ICMP Redirect
Quality of Service (QoS)
(VRRP)
IP
Association
VRID Address
10.1.0.254
10.1.4.254
3 10.1.8.253
4 10.1.12.253 1
150.100.0.4 1
in the Administration console or use
ip vrrp mode
Interval Priority Preempt
1 100 yes
1 100 yes
1 100 yes
100 yes
100 yes
