4 Enter executable instruction #3:

# not 0xffffffffffff

5 Enter executable instruction #4:

# accept packet and go no further

This accepts all non-broadcast packets.

6 Enter executable instruction #5:

# Get the type field of the packet and

# place it on top of the stack.

7 Enter executable instruction #6:

pushLiteral.w

# Put the type value for XNS on top

# of the stack.

8 Enter executable instruction #7:

# If the two values on the top of the stack are equal,

# then return a non-zero value.

This returns non-zero for XNS broadcast frames.

Packet Filter Two

This filter is designed to accept packets within the socket range of 0x76c

and 0x898. When combined with Filter One above, it forwards XNS

packets. Follow these steps to create this filter.

1 Name the filter:

"Socket range filter"

2 Enter executable instruction #1:

pushLiteral.w

# Put the lowest socket value on top

# of the stack.

3 Enter executable instruction #2:

# Put the value of the socket from the

# packet on top of the stack.

Long Custom Filter Example
