Administration Console Overview - 3Com corebuilder 3500 Implementation Manual

32 C 2: M
HAPTER ANAGEMENT
Administration
Console Overview
Menu options:(CoreBuilder-2B4200): --------------------------------------------
system
management
ethernet
fddi
bridge
ip
ipx
appletalk
qos
fastip
snmp
analyzer
log
script
logout
Type ? for help.
------------------------------------------------------------------------------
Select menu option:bridge
Menu options (CoreBuilder-2B4200):: ------------------------------------------
display
ipFragmentation
ipxSnapTranslation
addressThreshold
agingTime
stpState
stpPriority
stpMaxAge
stpHelloTime
stpForwardDelay
stpGroupAddress
gvrpState
port
packetFilter
vlan
trunk
Type "q" to return to the previous menu or ? for help.
------------------------------------------------------------------------------
Select menu option:bridge
Menu options (CoreBuilder-2B4200):: ------------------------------------------
display
ipFragmentation
ipxSnapTranslation
addressThreshold
agingTime
stpState
stpPriority
stpMaxAge
stpHelloTime
stpForwardDelay
stpGroupAddress
gvrpState
port
packetFilter
vlan
trunk
A
CCESS
The Administration Console is an internal character-oriented,
menu-driven, user interface for performing system administration such as
displaying statistics or changing option settings. You can view the
Administration Console from a terminal, a PC, a Macintosh, or from a
UNIX workstation. You can access the Administration Console through a
terminal or modem serial port, or through an Ethernet port using an
Internet Protocol (IP) interface.
Figure 1 shows a sample output of menu options that can be viewed
from the various devices.
Figure 1 Viewing the Administration Console
- Administer system-level functions
- Administer system management interface
- Administer Ethernet ports
- Administer FDDI resources
- Administer bridging
- Administer IP
- Administer IPX
- Administer Appletalk
- Administer QoS
- Administer FastIP
- Administer SNMP
- Administer Roving Analysis
- Administer Message Log
- Run a script of console commands
- Logout of the Administration Console
- Display bridge information
- Enable/Disable IP Fragmentation
- Enable/Disable IP 802.3-FDDI SNAP Translation
- Set the bridge address threshold
- Set the bridge aging time
- Enable/Disable Spanning Tree on a bridge
- Set the Spanning Tree bridge priority
- Set the Spanning Tree bridge maximum age
- Set the Spanning Tree bridge hello time
- Set the Spanning Tree bridge forward delay
- Set the Spanning Tree bridge group address
- Enable/disable GVRP
- Administer bridge ports
- Administer packet filters
- Administer VLANs
- Administer trunks
- Display bridge information
- Enable/Disable IP Fragmentation
- Enable/Disable IP 802.3-FDDI SNAP Translation
- Set the bridge address threshold
- Set the bridge aging time
- Enable/Disable Spanning Tree on a bridge
- Set the Spanning Tree bridge priority
- Set the Spanning Tree bridge maximum age
- Set the Spanning Tree bridge hello time
- Set the Spanning Tree bridge forward delay
- Set the Spanning Tree bridge group address
- Enable/disable GVRP
- Administer bridge ports
- Administer packet filters
- Administer VLANs
- Administer trunks
PC
UNIX workstation
Macintosh
Terminal
