502 C 17: Q S
HAPTER O
RSVP
AND
First classifier definition for filtering traffic to/from a specific
destination:
Classifier Field
Classifier Number
Classifier Name
Cast Type
IP protocol type
Source IP address
Source IP address mask
Destination IP address
Destination IP address mask
UDP source port range (start)
UDP source port range (end)
UDP destination port range (start)
UDP destination port range (end)
Add another filter (address/port pattern)? y
Source IP address
Source IP address mask
Destination IP address
Destination IP address mask
UDP source port range (start)
UDP source port range (end)
UDP destination port range (start)
UDP destination port range (end)
Add another filter (address/port pattern)? n
The control definition for the first filtering classifier:
Control Field
Control Number
Control Name
Rate Limit Type
Service Level
802.1p tag for forwarded frames
Classifiers controlled
Classifier Definition
1
192.20.3.3_to_193.20.3.3
all
all
192.20.3.3
255.255.255.255
193.20.3.3
255.255.255.255
0
65535
0
65535
193.20.3.3
255.255.255.255
192.20.3.3
255.255.255.255
0
65535
0
65535
Definition
5
192.20.3.3_to_193.20.3.3
none
best
none
1
