Example 6: Bridged Nonflow Ip Unicast Traffic - 3Com corebuilder 3500 Implementation Manual

508 C 17: Q S RSVP
HAPTER O AND
In this example, a nonflow classifier is defined to classify IP unicast traffic
Example 6: Bridged
Nonflow IP Unicast between clients and the server on the 168.101.0.0 network.
Traffic
The applied control handles this bridged traffic with a high priority
transmit service level and a rate limit of 75 percent of the link bandwidth.
Figure 91 Nonflow Classifier/Control for Bridged IP Unicast Traffic
Server
168.101.0.0 IP network
(255.255.0.0)
Clients
