Example 3: Gigabit
Ethernet Module
with Other Modules
P N
ORT UMBERING
When you have a system with one Gigabit Ethernet module and three
Fast Ethernet modules, port numbering accounts for the single port on
the Gigabit Ethernet module, as shown in Figure 8.
Figure 8 Port Numbering for a System with a Gigabit Ethernet Module
