484 C 17: Q
HAPTER
Classifier Name
20
Flow
23
401
402
403
404
405
406
407
Nonflow
420
430
440
450
460
470
480
490
499
Assigning Flow and
Nonflow Classifier
Numbers
S RSVP
O AND
Figure 82 Predefined Classifiers and Associated Controls
FTP
Telnet Traffic
Background
Standard
Business Critical
Streaming Multimedia
Interactive Multimedia
Interactive Voice
Network Control
TCP/IP
IP Unicast
IP Multicast
IP Broadcast
IPX Unicast
IPX Multicast/Broadcast
Appletalk Unicast
Appletalk Multicast/Broadcast
Default
Each classifier requires a unique number in the range 1 to 498. When you
define a classifier, the first information you supply is the classifier number.
The number you specify dictates which type of classifier you are defining.
The default classifier number is 499, which you cannot remove or modify.
Default
This is because all traffic passes through the QoS engine and the system
needs a classifier to handle all packets.
If you want to define a flow classifier (for routed IP packets only),
specify a value in the range of from 1 to 399. This allows you to
specify IP source and/or destination addresses as well as TCP or UDP
socket information.
If you want to define a nonflow classifier (for bridged or routed
packets), specify a value in the range of from 400 to 498. (See the list
of predefined nonflow classifiers in Figure 82.) For nonflow classifiers,
you cannot classify to the IP address or socket level.
Control Cast Protocol
none UM TCP
none UM TCP
2 UMB any
2 UMB any
3 UMB any
4 UMB any
4 UMB any
4 UMB any
4 UMB any
none U TCP/IP
none U IP
none M IP
none B IP
none U IPX
none MB IPX
none U Appletalk 0-7
none MB Appletalk 0-7
1 UMB any
802.1p
--
--
1
2
3
4
5
6
7
0-7
0-7
0-7
0-7
0-7
0-7
0-7
