Configuration of host systems

The host system must be setup to allow printing via the LinkCom 5 PrintServer. The
actual setup depends on the host system. If in doubt, please consult the host
system manual. Please note that the host system sees the LinkCom 5 PrintServer
as a printer.
8.1

Setup in mainframe TCP/IP environment

The descriptions in the sections below relate to the different print options from IBM
Mainframe / System z-series.
8.2

PSF/MVS AFP/IPDS printing

This section provides you with the PSF Start-up Procedures
Once these parameters have been configured, and the basic installation of the
LinkCom 5 PrintServer has been completed, direct AFP / IPDS from PSF / MVS is
possible.
Requirements:
 PSF/MVS version 2.2.0 with PTF level UW21345 or higher
 TCP/IP ver. 2, Rel. 1 or higher
 Interlink TCP/Access Ver.3.1 or higher
8.2.1

PSF/MVS start-up procedure

000001 //PSF4
000002 //STEP01 EXEC PGM=APSPPIEP,REGION=1750K
000034 //******************************************************************
000035 //*
000036 //*****************************************************************
000037 //PRT420 CNTL
000038
000058 //
000059 //
000060 //PRT420 ENDCNTL
Using IP address 192.0.110.21 and port number 5001.
The IP address of the LinkCom 5 PrintServer should be programmed in the IP-
address (IPADDR='192.0.110.21'). The port number (PORTNO=5001) is the default
port number of the IPDS port in print server.
8.3

PSS/MVS AFP/ICDS printing

This section provides:
PROC
.
.
.
STANDARD
//PRT420 PRINTDEV FONTDD=*.FONT01,
.
.
.
IPADDR='192.0.110.21'
PORTNO=5001
LinkCom 5 User Manual
PRINTDEV
/* FONT LIBRARY DD
/* IP ADDRESS
/* PORT NUMBER
*/
*/
*/
*/
