LinkCom 5 User Manual
7.3

Configuring logical printers

The PrintServer comes preloaded with the logical printers/transforms that have
been purchased with the PrintServer. All that has to be done, is to configure the
logical printer/transform that is required.
It is possible to configure IPDS, ICDS, DCA, SCS and TCP/IP port 9100 print,
however, the PrintServer can only serve one printer session at a time. E.g. if a host
system is printing AFP over IPDS through the PrintServer a simultaneous DCA print
job must wait for the IPDS job to complete before it can be processed.
7.4

Configuring AFP/IPDS transform

In PrintGuide, select and double-click the AFP/IPDS logical printer
This opens the configuration options:
7.4.1

PPD

The TCP/IP port number is default 5001. But can have any number between 100
and 32000
This is the port number the host system has to target in order to hit the IPDS
transform.
