Glue the two nylon clasp by C.A glue.

9. Installing the fuselage servos.

92
Install the first of the elevator servo.
95
Secure the servo arm.
98
Attach two metal clevis to the servo
arm and lock the cable.
10. Installing the fuel tank and the engine.
101
The engine mount
90
Install the wheel and the collar into the
tail gear.
93
Bend the first of the elevator pushrod.
96
Make the same way for the second of
the elevator servo.
99
Install the throttle servo.
102
Four holes
Mark four holes onto the F1 of the
fuselage.
Mustang P51
91
Install the tail gear into the fuslage and
secure it.
94
Attach the nylon clasp to the servo arm.
97
Install the rudder servo.
100
Install the metal connector to the servo
arm and secure the servo arm.
103
Drill four holes onto the F1 of the
fuselage.
