Instruction Manual
1. Installing the aileron and the flap servos
1
Remove the covering from the top of
the wing.
4
Insert the thread into the wing.
7
Pull the servo lead out.
10
Thread
Collar
Using the collars and prepare the thread
as a guide.
13
Pull the servo lead out.
2
Remove the covering from the aileron
servo box (at the bottom of the wing).
5
Prepare the aileron servo.
8
Secure the aileron servo.
11
Insert the thread into the the wing.
14
Using the masking tape, tape the servo
lead onto the top of the wing.
Mustang P51
3
Collar
Thread
Using the collar and prepare the thread
as a guide.
6
Tape
Tape the servo lead into the end of the
thread.
9
Remove the covering from the flap
servo box (at the bottom of the wing).
12
Tape the servo lead into the end of the
thread.
15
Aileron
Make the same way to install the aileron
servo and the flap servo for the second
wing.
Tape
Flap
