Phoenix Model Mustang P51 Instruction Manual page 6

Instruction Manual
46
Install the metal connector to the
landing gear.
49
Prepare the plastic part.
6. Installing the horizontal stabilizer and the vertical stabilizer.
52
Center line
Make a center line onto the horizontal.
55
Attach the horizontal to the fuselage
and check it.
57
Remove the covering from the bottom
of the horizontal.
4
47
Install two metal connector to the servo
arm of the gear servo.
50
Glue the plastic part to the landing gear.
53
Remove the covering from the rear of
the fuselage.
C1 C2
58
Remove the covering from the rear of
the vertical.
Mustang P51
48
Install the servo arm and attach two
rods to the metal connector.
51
Make the same way for installing the
second landing gear.
54
Cut away the covering from the
fuselage.
56
C1 = C2
Mark the shape of the fuselage onto the
bottom of the horizontal.
59
Insert the hinge into the slot.
