Phoenix Model TUCANO TURBOPROP Instruction Manual

SPECIFICATION
- Wingspan: 2567mm (101 in)
- Length: 2209mm (86.2 in)
- Flying weight: 16700 - 17700 gr
- Wing area: 100 dm2
- Wing loading: 167g/dm2
- Wing type: Naca airfoils
- Gear type: Electric Retract Gear With
CNC Suspension Metal Struts, Electric
Controller Box (included)
- Plastic Bomb not included
(purchasing separately)
- Spinner 3 blades: 105mm (Included)
- Radio: 8 channel minimum (Not Included)
- Servo: 8 standard hi-torque servo:
2 aileron; 2 flap; 2 elevator; 1 rudder;
1 steering nose (Not included)
- Servo mount: 21mm x 42 mm
- Propeller: suit with your engine
- Engine: Turboprop Kingtech K-45
(Not Included)
TUCANO TURBOPROP
2,567m 101" W/Electric Retract ARF CARBON
- Gravity CG: 141 mm (5.5 in) Back from
the leading edge of the wing, at the fuselage
- Control throw Ailerons: Low: 15mm up/down;
High: 20mm up/down
- Control throw Elevators: Low: 15mm up/down;
High: 20mm up/down
- Control throw Rudder: Low: 30mm right/left;
High: 45mm right/left
- Control throw Flaps: Mid: 25mm down;
Landing: 35mm down
- Experience level: Intermediate
- Plane type: Scale Military
UNDER SAFETY PRECAUTIONS
This radio control model is not a toy!
It is highly recommended that first-time builders seek advice of
experienced modelers before beginning assembly.
Assemble this kit only in places out of children's reach!
Take enough safety precautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
Always keep this instruction manual ready at hand for quick
reference, even after completing the assembly.
