This is a Mini ITX form factor (6.7"x6.7", 17.0x17.0 cm) motherboard. Before you install the
motherboard, study the configuration of your chassis to ensure that the motherboard fits into it.
Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so may cause physical injuries to you and damages to
motherboard components.
Note
3.1

Screw Holes

Place screws into the holes to secure the motherboard to the chassis
Do not over-tighten the screws! Doing so may damage the motherboard.
Note
3.2

Pre-installation Precautions

Take note of the following precautions before you install motherboard components or change
any motherboard settings
1. Unplug the power cord from the wall socket before touching any component.
2. To avoid damaging the motherboard components due to static electricity, NEVER place
your motherboard directly on the carpet or the like. Also remember to use a grounded
wrist strap or touch a safety grounded object before you handle components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded antistatic pad or in the
bag that comes with the component.
Before you install or remove any component, ensure that the power is switched off
or the power cord is detached from the power supply. Failure to do so may cause
severe damage to the motherboard, peripherals and/or components.
Note
