2.4

Headers and Connectors

Signals go to other parts of the system through headers and connectors. Loose or improper
connection might cause problems, please make sure all headers and connectors are properly
and firmly connected. Here is a summary table showing headers and connectors on the
hardware.
Onboard headers and connectors are NOT jumpers. Do NOT place jumper clips
over these headers and connectors. Placing jumper clips over the headers and
connectors will cause permanent damage of the motherboard!
Note
Header and Connector
BLT_PWR1
BLT_VOL1
ATXPWR1
PS2_KB_MS1
COM4~COM6
CPU_FAN1
CI1~CI2
CON1
PANEL1
SPEAKER1
JGPIO1
CHA_FAN1
SATA_0~SATA_1
SATA_4~SATA_5
HD_AUDIO1
USB4_5, USB8_9, USB10_11
LVDS1
PCIE1
mini-SATA
DDR3_A1
DDR3_B1
Board and Pin Assignments
MANO881 Series All-In-One Mini ITX Board
Description
Backlight Power Connector
Backlight Volume Control Connector
24-pin ATX Power Input Connector
PS/2 Keyboard and Mouse Connector
RS-232 Port Headers
4-pin +12V CPU Fan Connector
Chassis Intrusion Headers
4-pin ATX Power Input Connector
System Panel Header
3W Audio AMP Output Wafer
Digital I/O Header
4-pin +12V Chassis Fan Connector
SATA 3.0 Connectors
SATA 2.0 Connectors
Front Panel Audio Header
USB 2.0 Headers
LVDS Panel Connector
PCI-Express x16 Slot
mSATA Slot
204-pin DDR3 SO-DIMM Socket A1
204-pin DDR3 SO-DIMM Socket B1
9
