EPSON Stylus Photo RX700

1.1 Overview

Stylus Photo RX700, incorporating a color inkjet printer, image scanner and memory
card slot, is provided with the following functions.
Printing: The product works as a PC printer as well as a standalone printer
that directly prints image data in the memory card inserted to the
card slot.
And the product works as a CD-R/DVD±R printing.
Image scanning: The product works as a PC image scanner. It can also save
acquired image to the memory card inserted to the memory card
slot of the product.
A film scanning function with the TPU (transparency unit) is
available as a standard feature.
Copying: The product works as a standalone copier.
Memory card slot:
The memory card slot can be used as a USB memory card slot
for a PC.
Color LCD: The color LCD is incorporated as a standard component for easy
operation.
USB Host: Data in storage devices can be printed.
Memory card information can be backed up into a storage
device.
Bluetooth or IrDA wireless connection is available as an
optional feature.
Product Description

1.1.1 Printer and PC Printing

Basic specifications
Table 1-1. Printer Basic Specifications
Items
Type
Print Head
Number of nozzles
Number of inks
Colors of inks
Type of ink
Maximum print resolution
Minimum size of dot
Other functions and goals
Paper inputs
Table 1-2. Paper Loading Specifications
Items
Auto Sheet Feeder Type
Capacity*
Other paper inputs
Note "*": Paper thickness = 0.1mm
Overview
Specifications
F-Mach
Black : 180
Color : 180 x 5
6 colors
Black, Cyan, Magenta, Yellow, Light-Cyan, Light-Magenta
Black & Color: HQ4
5760 x 1440 dpi
1.5 pl
Preferred Color
BorderFree printing
Silent paper loading
Double paper path
Sensor for paper width
Specifications
New design
Front in Front out: Plain Paper, A4 (Euro) only,
Letter (EAI) only
Top in Front out: All type paper, thicker Paper)
Front ASF: Plain paper: 150 sheets
Top ASF: Plain paper: 120 sheets
PGPP: 20 sheets
CD-R/DVD±R (with CD Try)
Revision B
10
