Destination 2.3
Insert
(EB00021 model)
After-sale service: 418-908-8002
READ AND KEEP THIS MANUAL FOR REFERENCE
This manual is available for free download on the manufacturer's web site. It is a
copyrighted document. Re-sale is strictly prohibited. The manufacturer may update this
manual from time to time and cannot be responsible for problems, injuries, or damages
arising out of the use of information contained in any manual obtained from unauthorized
sources.
Printed in Canada
www.enerzone-intl.com
Stove Builder International Inc.
250, rue de Copenhague, St-Augustin-de-Desmaures
(Quebec) Canada G3A 2H3
INSTALLATION
AND OPERATION
MANUAL
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED
WOOD INSERT
Safety tested according to ULC S628,
UL 737 and UL 1482 Standards
by an accredited laboratory
E-mail: tech@sbi-international.com
45595A
29-04-2016
Advertisement
Table of Contents
Related Manuals for Enerzone Destination 2.3 Insert
Summary of Contents for Enerzone Destination 2.3 Insert
- Page 1 WOOD INSERT Insert (EB00021 model) Safety tested according to ULC S628, UL 737 and UL 1482 Standards by an accredited laboratory www.enerzone-intl.com Stove Builder International Inc. 250, rue de Copenhague, St-Augustin-de-Desmaures (Quebec) Canada G3A 2H3 After-sale service: 418-908-8002 E-mail: tech@sbi-international.com READ AND KEEP THIS MANUAL FOR REFERENCE This manual is available for free download on the manufacturer’s web site.
- Page 2 THANK YOU FOR CHOOSING THIS ENERZONE WOOD INSERT As one of North America’s largest and most respected wood stove and fireplace manufacturers, Stove Builder International takes pride in the quality and performance of all its products. We want to help you get maximum satisfaction as you use this product.
-
Page 3: Table Of Contents
PART A - OPERATION AND MAINTENANCE ........6 1 Safety Information ................6 Summary of Operation and Maintenance Cautions and Warnings ........6 2 General Informationon Destination 2.3 Insert (EB00021) ....7 Appliance performance ....................7 General Features ......................8 Zone Heating and How to Make it Work for You .............. - Page 4 The Relationship Between the Chimney and the House ..........42 9.7.1 Why the chimney should penetrate the highest heated space ........42 Supply of Combustion Air ....................43 9.8.1 Air Supply in Conventional Houses ................43 Destination 2.3 Insert Installation and Operation Manual...
- Page 5 Appendix 5: Installing the Optional Fire Screen (AC01315) ....51 Appendix 6: Installation of Secondary Air Tubes and Baffle ..... 52 Appendix 7: Removal instructions ............54 Appendix 8: Exploded Diagram and Parts List ........55 ENERZONE LIMITED LIFETIME WARRANTY ......58 Destination 2.3 Insert Installation and Operation Manual...
-
Page 6: Part A - Operation And Maintenance
INSERT FAILS TO FUNCTION CORRECTLY. IF YOU ARE REQUIRED TO INSTALL AN OUTDOOR AIR SUPPLY, WE RECOMMEND THAT YOU ALSO INSTALL A CO DETECTOR/ALARM TO PROVIDE WARNING IF SMOKE SPILLAGE FROM THE INSERT OCCURS. Destination 2.3 Insert Installation and Operation Manual... -
Page 7: General Informationon Destination 2.3 Insert (Eb00021)
Higher Heating Value of the fuel. Lower Heating Value of the fuel. Optimum overall efficiency at a specific burn rate (LHV). This appliance is officially tested and certified by an independent agency. Carbon monoxide. Destination 2.3 Insert Installation and Operation Manual... -
Page 8: General Features
CAN/CSA-Z240 MH standard Destination 2.3 Insert Installation and Operation Manual... - Page 9 Destination 2.3 Insert Installation and Operation Manual...
-
Page 10: Zone Heating And How To Make It Work For You
The emission control and advanced combustion features of your insert can only work properly if your fuel is in the correct moisture content range of 15 to 20 percent. See Section A3.0 of this manual for suggestions on preparing fuelwood and judging its moisture. Destination 2.3 Insert Installation and Operation Manual... -
Page 11: The Sbi Commitment To You And The Environment
Ceramic glass cannot be recycled in the same way as normal glass, so it should not be disposed of with your regular household products. Disposal at a landfill is recommended. Destination 2.3 Insert Installation and Operation Manual... -
Page 12: Fuel
That is no longer true. You can successfully heat your home by using the less desirable tree species and give the forest a break at the same time. Destination 2.3 Insert Installation and Operation Manual... -
Page 13: Log Length
Having a range of sizes makes starting and rekindling fires much easier. Often, the firewood purchased from commercial suppliers is not split finely enough for convenient stoking. It is sometimes advisable to resplit the wood before stacking to dry. Destination 2.3 Insert Installation and Operation Manual... -
Page 14: How To Dry Firewood
• firewood that is ready to burn has a moisture content between15 and 20% by weight and will allow your insert to produce its highest possible efficiency Destination 2.3 Insert Installation and Operation Manual... -
Page 15: Judging Firewood Moisture Content
Start with one manufactured log and see how the insert reacts. Never use more than two manufactured logs. Destination 2.3 Insert Installation and Operation Manual... -
Page 16: Operating Your Insert
A fire that starts fast produces less smoke and deposits less creosote in the chimney. Here are three popular and effective ways to start wood fires. Destination 2.3 Insert Installation and Operation Manual... -
Page 17: Conventional Fire Starting
Place two spit logs in the firebox. Place a few sheets of twisted newspaper between the logs. Now place some fine kindling across the two logs and some larger kindling across those, log cabin style. Light the newspaper. Destination 2.3 Insert Installation and Operation Manual... -
Page 18: Using Fire Starters
The best time to remove ash is after an overnight fire when the insert is relatively cool, but there is still some chimney draft to draw the ash dust into the insert and prevent it from coming into the room. Destination 2.3 Insert Installation and Operation Manual... -
Page 19: Raking Charcoal
Although it is important to fire each new load hot to prepare for a clean burn, do not allow the fire to burn at full intensity for more than a few minutes. DO NOT LEAVE THE INSERT UNATTENDED WHILE A NEW LOAD IS BEING FIRED HOT. DO NOT OVERFIRE. Destination 2.3 Insert Installation and Operation Manual... -
Page 20: Turning Down The Air Supply
With good fuel and correct air control use, the flames should slow down, but should stay large and steady, even as the air supply is reduced. Destination 2.3 Insert Installation and Operation Manual... -
Page 21: Blower Operation
You will need to be cautious when building fires like this because if the air is turned down too much, the fire could smoulder. Make sure the wood is flaming brightly before leaving the fire to burn. Destination 2.3 Insert Installation and Operation Manual... - Page 22 North-south loads break down more quickly, but much more wood can be loaded at a time. This makes north-south loading good for high output, long lasting fires for cold weather. Destination 2.3 Insert Installation and Operation Manual...
-
Page 23: Maintaining Your Wood Heating System
Visit your insert retailer to get the self-adhesive glass gasket and follow the instructions below for installation. Do not abuse the glass door by striking or slamming shut. Do not use the insert if the glass is broken. Destination 2.3 Insert Installation and Operation Manual... -
Page 24: Door Adjustment
Tuck any loose fibres under the gasket and into the silicone. Close the door and do not use the insert for 24 hours. Destination 2.3 Insert Installation and Operation Manual... -
Page 25: Replacing The Glass Gasket And/Or The Glass
Do not abuse the glass door by striking or slamming shut. Do not use the insert if the glass is broken. To change the glass, perform the same operation described above. Destination 2.3 Insert Installation and Operation Manual... -
Page 26: Cleaning And Painting The Insert
Use a plastic or steel brush. Contact your local municipal or provincial fire authority for information on how to handle a chimney fire. Have a clearly understood plan to handle a chimney fire. Destination 2.3 Insert Installation and Operation Manual... -
Page 27: Cleaning The Chimney
Check the firebrick for damage at least annually and replace any broken or damaged ones with new ones. Inspection and cleaning of the chimney is facilitated by the removable baffle. Destination 2.3 Insert Installation and Operation Manual... -
Page 28: Part B - Installation
Your local inspector should have information on whether older fireplaces are of adequate construction. 5. OPENING SIZE: Refer to “MINIMUM MASONRY OPENING” (Section 8.5) for suitable size fireplace openings. Destination 2.3 Insert Installation and Operation Manual... -
Page 29: Safety Information
Vents, or CAN/ULC-S640, Standard for Lining Systems for New Masonry Chimneys. NOTE: The Insert is not approved for use with a so-called “positive flue connection” to the clay tile of a masonry chimney. Destination 2.3 Insert Installation and Operation Manual... -
Page 30: Clearances To Combustible Material
(27009), supplied with the owner’s manual kit, indicating that the masonry hearth has been modified. It must be secured inside the masonry hearth, in a visible place and easy to locate. Destination 2.3 Insert Installation and Operation Manual... -
Page 31: Compliance Of A Combustible Mantel Shelf
(11 5/8" (295 mm) + 9" (229 mm)). MAXIMUM MANTEL MANTEL SHELF SHELF DIMENSION (X) CLEARANCES (I) 8" / 203 mm 19 5/8" (498 mm) 10" / 254 mm 21 5/8" (549 mm) 12" / 305mm 23 5/8" (600 mm) Destination 2.3 Insert Installation and Operation Manual... -
Page 32: Positioning The Unit
R factor of 1.24 or more extending 16 " (406 mm USA) and 18” (457 mm Canada) in front of the door opening. 5" 5" 127 mm 127 mm Destination 2.3 Insert Installation and Operation Manual... - Page 33 Four inches of brick (R = 4 x 0,2 = 0,8) plus 1 inch of Durock (R = 1 x 0.52 = 0.52). 0.8 + 0.52 = 1.32. This R value is larger than the required 1.00 and is therefore acceptable Destination 2.3 Insert Installation and Operation Manual...
- Page 34 The choice of the configuration will depend on, the previous installation instructions and compliance with building code. To determine the minimum and maximum projection of the insert, refer to table Data for floor protection calculation. Destination 2.3 Insert Installation and Operation Manual...
- Page 35 CAN: 457 mm 51 / 102 254 / 305 extension 2" or 4" MILLIMETRES D = B - (A - C) USA: 406 mm ( 51 or 102 mm) Destination 2.3 Insert Installation and Operation Manual...
-
Page 36: Minimum Masonry Opening, Clearances To Combustibles, And Floor Protector
5" 5" 127 mm 127 mm 8.5 Minimum Masonry Opening, Clearances to Combustibles, and Floor Protector Destination 2.3 Insert Installation and Operation Manual... - Page 37 5” (127 mm), the non-combustible floor protector (B) in front of the insert should have an R value equal or greater than 1.24 and should extend at least 20" (508 mm) in front of the unit. Destination 2.3 Insert Installation and Operation Manual...
-
Page 38: The Venting System
In Canada, CSA B365 Standard permits the use of ‘’Roxul’’ type wool stuffed around the liner as it passes through the throat area as an alternative to a sheet metal Block-off plate. However, this method is inferior to the use of a sheet metal block-off plate. Destination 2.3 Insert Installation and Operation Manual... -
Page 39: Suitable Chimneys
If lag-bolts or anchors are to be used to secure the insert, the hole locations should be marked with the unit in place. Remove the insert and locate the anchors. Destination 2.3 Insert Installation and Operation Manual... -
Page 40: Chimney Liner Installation
The long end of the brackets must be attached to the insert. Insert the chimney liner into the flue collar of the unit and secure the liner to the brackets with three self-tapping screws (not included). Destination 2.3 Insert Installation and Operation Manual... -
Page 41: If The Chimney Liner Does Not Align With The Insert's Flue Outlet
The brackets and screws are in the insert’s owner’s manual kit. Then follow the instructions in the manual provided with the liner offset adapter kit. Destination 2.3 Insert Installation and Operation Manual... -
Page 42: Minimum Chimney Height
Even the finest insert will not work well when connected to this chimney. Destination 2.3 Insert Installation and Operation Manual... -
Page 43: Supply Of Combustion Air
Check the outdoor air duct for soot deposits when the full system is cleaned and inspected at least once each year. Destination 2.3 Insert Installation and Operation Manual... -
Page 44: Appendix 1: Reversing The Door Opening And Adjusting The Handle
Appendix 1: Reversing the Door Opening and Adjusting the Handle Destination 2.3 insert is equipped with a reversible door in case you prefer a door opening on the other side. Follow the steps below if you wish to avail yourself of this feature: 1. - Page 45 5. Screw the nut (N) to secure the mechanism. 6. Reinstall the handle guide (P) with the 2 bolts (A). To adjust the tightness of the door with spacers (B), see Section 5.1.2 Door adjustment. Destination 2.3 Insert Installation and Operation Manual...
-
Page 46: Appendix 2: Installing The Optional Fresh Air Intake Kit (Ac01298)
(D). Secure the other end of the pipe to the outside wall termination using second adjustable pipe clamp (D). The outside wall termination (F) must be installed outside of the building. Destination 2.3 Insert Installation and Operation Manual... -
Page 47: Appendix 3: Faceplate Installation
1. Secure the blower switch assembly (C) to the faceplate (A) with 2 screws (D). 2. Align the holes in the support bracket of faceplate (A) with the screws (E) already installed on the insert, then tighten the screws. Use the same procedure for faceplate (B). Destination 2.3 Insert Installation and Operation Manual... - Page 48 3. Align the holes in the support bracket of faceplate (F) then tighten the screws (H) already installed on the insert. 4. Align the holes in the support bracket of faceplate (G) then tighten the screws (H) already installed on the insert. Destination 2.3 Insert Installation and Operation Manual...
-
Page 49: Appendix 4: Blower Replacement
3. Slightly loosen the 4 wing nut (C) then pull the blower assembly (D) towards you to remove it from the convection air jacket. Make sure to disconnect the wiring as it is accessible. Destination 2.3 Insert Installation and Operation Manual... - Page 50 Destination 2.3 Insert Installation and Operation Manual...
-
Page 51: Appendix 5: Installing The Optional Fire Screen (Ac01315)
Lift the fire screen upwards and push the bottom part towards the stove then let the fire screen rest on the bottom of the door opening. Warning: Never leave the stove unattended while in use with the fire screen. Destination 2.3 Insert Installation and Operation Manual... -
Page 52: Appendix 6: Installation Of Secondary Air Tubes And Baffle
3. Repeat steps 1 and 2 for the two tubes in the back then install the baffle before installing the two front tubes. 4. To remove the tubes use the above steps in reverse order. Destination 2.3 Insert Installation and Operation Manual... - Page 53 Model Type of tube Destination 2.3 insert Front ► 30 holes of 0.147" Middle front ► 30 holes of 0.136’’ Middle rear ► 20 holes of 0.128’’ Rear ► 15 holes of 0.128’’ Destination 2.3 Insert Installation and Operation Manual...
-
Page 54: Appendix 7: Removal Instructions
Remove the screws that secure the chimney liner to the fixation brackets (E). • Unscrew the leveling bolts (F) located on each side of the insert. • Pull-out the insert from the fireplace opening to perform the maintenance work. Destination 2.3 Insert Installation and Operation Manual... -
Page 55: Appendix 8: Exploded Diagram And Parts List
Appendix 8: Exploded Diagram and Parts List Destination 2.3 Insert Installation and Operation Manual... - Page 56 GLASS WITH TOP AND BOTTOM TINTED STRIP AND GASKET 30 AC06400 BLACK SELF-ADHESIVE GLASS GASKET KIT (6') 31 PL65751 GLASS FRAME 32 SE63024 GLASS RETAINER WITH SCREWS KIT (10 PER KIT) 33 PL65623 DOOR LATCH Destination 2.3 Insert Installation and Operation Manual...
- Page 57 AIR CONTROL DAMPER ASSEMBLY 40 30187 ZINC WASHER ID 17/64" X OD 1/2" 41 SE45595 INSTRUCTION MANUEL KIT DESTINATION 2.3 INSERT STOVE 42 AC05959 METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL 43 AC01298 FRESH AIR INTAKE KIT - 5" DIAMETER 44 30337 SQUARE HEAD SET SCREW 1/2-13 X 1-3/4"...
-
Page 58: Enerzone Limited Lifetime Warranty
Labour cost and repair work to the account of the manufacturer are based on a predetermined rate schedule and must not exceed the wholesale price of the replacement part. Shall your unit or a components be defective, contact immediately your ENERZONE dealer. To accelerate processing of your warranty claim, make sure to have on hand the following information when calling: •...
