READ AND KEEP THIS MANUAL FOR REFERENCE
This manual is available for free download on the manufacturer's web site. It is a
copyrighted document. Re-sale is strictly prohibited. The manufacturer may update this
manual from time to time and cannot be responsible for problems, injuries, or damages
arising out of the use of information contained in any manual obtained from unauthorized
sources.
Printed in Canada
INSTALLATION
AND OPERATION
MANUAL
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED
WOOD INSERT
www.enerzone-intl.com
Stove Builder International Inc.
250, rue de Copenhague,
St-Augustin-de-Desmaures
(Quebec) Canada G3A 2H3
Tel: (418) 878-3040
Fax: (418) 878-3001
45765A
19-09-2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Enerzone Destination 1.5
Summary of Contents for Enerzone Destination 1.5
- Page 1 INSTALLATION AND OPERATION MANUAL US ENVIRONMENTAL PROTECTION Destination 1.5 AGENCY PHASE II CERTIFIED WOOD INSERT Insert Safety tested according to ULC S628 and UL 1482 Standards by Intertek Testing Services www.enerzone-intl.com Stove Builder International Inc. 250, rue de Copenhague, St-Augustin-de-Desmaures...
- Page 2 THANK YOU FOR CHOOSING THIS ENERZONE WOOD INSERT As one of North America’s largest and most respected wood stove and fireplace manufacturers, Stove Builder International takes pride in the quality and performance of all its products. We want to help you get maximum satisfaction as you use this product.
-
Page 3: Table Of Contents
Raking Charcoal ......................18 4.3.4 Firing Each New Load Hot .................... 19 4.3.5 Turning Down the Air Supply ..................19 4.4 Optional Fan Operation ..................... 20 4.4.1 Building Different Fires for Different Needs ..............20 Destination 1.5 Insert Installation and Operation Manual... - Page 4 The Relationship Between the Chimney and the House ..........41 9.7.1 Why the chimney should penetrate the highest heated space ........41 9.8 Supply of Combustion Air ....................42 9.8.1 Air Supply in Conventional Houses ................42 Destination 1.5 Insert Installation and Operation Manual...
- Page 5 Appendix 5: Installation of Secondary Air Tubes and Baffle ... 53 Appendix 6: Removal instructions ..........56 Appendix 7: Exploded Diagram and Parts List ......57 ENERZONE LIMITED LIFETIME WARRANTY ......60 Destination 1.5 Insert Installation and Operation Manual...
-
Page 6: Part A - Operation And Maintenance
START A FIRE IN THIS INSERT. KEEP ALL SUCH LIQUIDS OR AEROSOLS WELL AWAY FROM THE INSERT WHILE IT IS IN USE. • DO NOT STORE FUEL WITHIN HEATER MINIMUM INSTALLATION CLEARANCES. • BURN ONLY SEASONED NATURAL FIREWOOD. Destination 1.5 Insert Installation and Operation Manual... - Page 7 REASON THE WOOD INSERT FAILS TO FUNCTION CORRECTLY. IF YOU ARE REQUIRED TO INSTALL AN OUTDOOR AIR SUPPLY, WE RECOMMEND THAT YOU ALSO INSTALL A CO DETECTOR/ALARM TO PROVIDE WARNING IF SMOKE SPILLAGE FROM THE INSERT OCCURS. Destination 1.5 Insert Installation and Operation Manual...
-
Page 8: General Information
This insert is not intended to operate at its peak heat output continuously. *** East-west: through the door you see the sides of the logs; north-south: through the door you see the ends of the logs. Destination 1.5 Insert Installation and Operation Manual... - Page 9 Installation on blower assembly with bottom facing (AC01351) Destination 1.5 Insert Installation and Operation Manual...
- Page 10 Installation with bottom facing without blower (AC01352) Destination 1.5 Insert Installation and Operation Manual...
-
Page 11: Zone Heating And How To Make It Work For You
2.2 Zone Heating and How to Make it Work for You Your new Destination 1.5 wood insert is a space heater, which means it is intended to heat the area it is installed in, as well as spaces that connect to that area, although to a lower temperature. -
Page 12: The Benefits Of Low Emissions And High Efficiency
2.3 The Benefits of Low Emissions and High Efficiency The low smoke emissions produced by the special features inside the Destination 1.5 firebox mean that your household will release up to 90 percent less smoke into the outside environment than if you used an older conventional stove. -
Page 13: Fuel
That is no longer true. You can successfully heat your home by using the less desirable tree species and give the forest a break at the same time. Destination 1.5 Insert Installation and Operation Manual... -
Page 14: Log Length
Continually burning green or unseasoned wood produces more creosote and involves lack of heat and dirty glass door. See Section 5: Maintaining your wood heating system for concerns about creosote. Destination 1.5 Insert Installation and Operation Manual... -
Page 15: Judging Firewood Moisture Content
100% compressed sawdust can be burned, but use caution in the number of these logs burned at one time. Start with one manufactured log and see how the insert reacts. Never use more than two manufactured logs. Destination 1.5 Insert Installation and Operation Manual... -
Page 16: Operating Your Insert
ALWAYS CLOSE AND LATCH THE DOOR AFTER THE FIRE IGNITES. After the kindling fire has mostly burned, you can add standard firewood pieces until you have a fire of the right size for the conditions. Destination 1.5 Insert Installation and Operation Manual... -
Page 17: The Top Down Fire
Wood burns best in cycles. A cycle starts when a new load of wood is ignited by hot coals and ends when that load has been consumed down to a bed of charcoal about the same size as it was Destination 1.5 Insert Installation and Operation Manual... -
Page 18: Ash Removal
If you were to simply spread the charcoal out, the new load will smoulder for a long time before igniting. Destination 1.5 Insert Installation and Operation Manual... -
Page 19: Firing Each New Load Hot
With good fuel and correct air control use, the flames should slow down, but should stay large and steady, even as the air supply is reduced. Destination 1.5 Insert Installation and Operation Manual... -
Page 20: Optional Fan Operation
You will need to fire the load hot for long enough to fully char the log surfaces before you can turn the air down. Make sure the fire is flaming brightly before leaving the fire to burn. Destination 1.5 Insert Installation and Operation Manual... - Page 21 North-south loads break down more quickly, but much more wood can be loaded at a time. This makes north-south loading good for high output, long lasting fires for cold weather. Destination 1.5 Insert Installation and Operation Manual...
-
Page 22: Maintaining Your Wood Heating System
Visit your insert retailer to get the self-adhesive glass gasket and follow the instructions below for installation. Do not abuse the glass door by striking or slamming shut. Do not use the insert if the glass is broken. Destination 1.5 Insert Installation and Operation Manual... -
Page 23: Door Adjustment
Now run a 1/4” (6 mm) bead of high temperature silicone in the door gasket groove. Starting from the middle of the hinge side, press Destination 1.5 Insert Installation and Operation Manual... -
Page 24: Replacing The Glass Gasket And/Or The Glass
2. Remove the screws (A) holding in place the upper glass retainer (B) and the lower glass retainer (C) to the door frame (D). 3. Remove glass (F) and the decorative accent plate (E). 4. Repeat the steps in reverse order to install the new glass. Destination 1.5 Insert Installation and Operation Manual... - Page 25 Do not abuse the glass door by striking or slamming shut. Do not use the insert if the glass is broken. To change the glass, perform the same operation described above. Destination 1.5 Insert Installation and Operation Manual...
-
Page 26: Cleaning And Painting The Insert
Use a plastic or steel brush. Contact your local municipal or provincial fire authority for information on how to handle a chimney fire. Have a clearly understood plan to handle a chimney fire. Destination 1.5 Insert Installation and Operation Manual... -
Page 27: Cleaning The Chimney
Inspection and cleaning of the chimney can be facilitated by removing the baffle. CAUTION: OPERATION OF YOUR DESTINATION 1.5 WITHOUT THE BAFFLE MAY CAUSE UNSAFE AND HAZARDOUS TEMPERATURE CONDITIONS AND WILL VOID THE WARRANTY. NOTE: Before installing the firebrick, check to ensure that none are broken or damaged in any way, and replace the damaged ones. -
Page 28: Part B - Installation
Your local inspector should have information on whether older fireplaces are of adequate construction. 5. OPENING SIZE: Refer to “MINIMUM MASONRY OPENING” (Section 8.5) for suitable size fireplace openings. Destination 1.5 Insert Installation and Operation Manual... -
Page 29: Safety Information
THE INSERT AND ITS STAINLESS STEEL CHIMNEY LINER ARE TO BE INSTALLED ONLY WITHIN A LINED MASONRY CHIMNEY AND MASONRY FIREPLACE CONFORMING TO BUILDING CODES FOR USE WITH SOLID FUEL. DO NOT REMOVE BRICKS OR MORTAR FROM THE EXISTING FIREPLACE WHEN INSTALLING THE INSERT. Destination 1.5 Insert Installation and Operation Manual... -
Page 30: Regulations Covering Insert Installation
7.2 Regulations Covering Insert Installation When installed and operated as described in these instructions, the Destination 1.5 wood insert is suitable for use in residential installations. The Destination 1.5 wood insert is not intended for installation in a bedroom. In Canada, the CSA B365 Installation Code for Solid Fuel Burning Appliances and Equipment and the CSA C22.1 Canadian National Electrical Code are to be followed in the absence of local code... -
Page 31: The Masonry Fireplace's Draft Control System (Throat Damper)
(D) is negative or zero, you do not have to add more floor protection in front of the unit, because the masonry fireplace hearth extension is large enough. If the value (D) is positive, you will need floor protection in front of the hearth extension at least equivalent to the result (D). Destination 1.5 Insert Installation and Operation Manual... - Page 32 If the extension of the masonry hearth is raised at least 8" (F) from the floor protection, a non- combustible material without an R factor extending 16 " (406 mm) (USA)/18’’ (457 mm) (CAN) from the front of the insert is required. Destination 1.5 Insert Installation and Operation Manual...
- Page 33 Four inches of brick (R = 4 x 0,2 = 0,8) plus 1 inch of Durock (R = 1 x 0.52 = 0.52). 0.8 + 0.52 = 1.32. This R value is larger than the required 1.00 and is therefore acceptable Destination 1.5 Insert Installation and Operation Manual...
- Page 34 * Information as reported by manufacturers and other resources ** For a 1/8" thickness. You cannot «stack» horizontal still air to accumulate R-values; you must separate each layer of horizontal still air with another non-combustible material. Destination 1.5 Insert Installation and Operation Manual...
- Page 35 CAN/USA: 22" 0" D = B - (A - C) 12 1/8" Flush with the hearth fireplace CAN/USA: MILLIMETRES 0 mm D = B - (A - C) 308 mm extension facing 559 mm Destination 1.5 Insert Installation and Operation Manual...
-
Page 36: Minimum Masonry Opening, Clearances To Combustibles, And Floor Protector
8.5 Minimum Masonry Opening, Clearances to Combustibles, and Floor Protector Destination 1.5 Insert Installation and Operation Manual... - Page 37 If the hearth elevation is lower than 8 inches, the non-combustible floor protector in front of the insert should have an R value equal or greater than 2.00. Destination 1.5 Insert Installation and Operation Manual...
-
Page 38: The Venting System
In Canada, CSA B365 Standard permits the use of ‘’Roxul’’ type wool stuffed around the liner as it passes through the throat area as an alternative to a sheet metal Block-off plate. However, this method is inferior to the use of a sheet metal block-off plate. Destination 1.5 Insert Installation and Operation Manual... -
Page 39: Suitable Chimneys
If lag-bolts or anchors are to be used to secure the insert, the hole locations should be marked with the unit in place. Remove the insert and locate the anchors. Destination 1.5 Insert Installation and Operation Manual... -
Page 40: Chimney Liner Installation
(the insert’s baffle will need to be removed prior to that). Then, the liner can be secured to the insert’s flue outlet using a screwless attachment system fixed to the interior insert’s combustion chamber. See drawing on the right. Destination 1.5 Insert Installation and Operation Manual... -
Page 41: Minimum Chimney Height
Even the finest insert will not work well when connected to this chimney. Destination 1.5 Insert Installation and Operation Manual... -
Page 42: Supply Of Combustion Air
Check the outdoor air duct for soot deposits when the full system is cleaned and inspected at least once each year. Destination 1.5 Insert Installation and Operation Manual... -
Page 43: Appendix 1: Optional Blower Assembly With Bottom Facing (Ac01351) Installation
Appendix 1: Optional Blower Assembly With Bottom Facing (AC01351) Installation Remove the door (A) and all bricks (B) from the firebox. Lean the insert on its back. Install the base (C) under the unit. Destination 1.5 Insert Installation and Operation Manual... - Page 44 Using a power driver with a hex head 5/16" (8 mm), secure the base with 3 screws (D) on each side of the insert. Install the 4 leveling bolts (E) in the nuts located at the bottom of the insert with a 1/2" (13 mm) wrench. Destination 1.5 Insert Installation and Operation Manual...
- Page 45 Using a power driver with a Philips end, secure the top facing (F) on the insert with 2 screws (G). Place the insert back up. Install all the bricks (B) back in the firebox and put the door (A) back in place. Destination 1.5 Insert Installation and Operation Manual...
-
Page 46: Appendix 2: Optional Bottom Facing Without Blower (Ac01352) Installation
Open the door. Using a power driver with a Philips end, secure the bottom facing (A) on the insert with 2 screws (B). Install the 4 leveling bolts (E) in the nuts located at the bottom of the insert with a 1/2" (13 mm) wrench. Destination 1.5 Insert Installation and Operation Manual... -
Page 47: Appendix 3: Optional 29" H X 44" W Backing Plate (May Be Cut To 26"H) Installation
1. Using Philips screwdriver, remove the air control damper wooden handle secured by a screw (B). Destination 1.5 Insert Installation and Operation Manual... - Page 48 Using a power driver with Philips end, remove the top (C) and bottom (D) facings held in place with screws (E). 3. Slide the backing plate (F) behind the frame of the insert. Destination 1.5 Insert Installation and Operation Manual...
- Page 49 4. Using a power driver with Philips end, secure backing plate to the frame with 6 screws (F). Destination 1.5 Insert Installation and Operation Manual...
-
Page 50: Appendix 4: Blower Replacement
1. Using a power driver with a Philips end, remove the bottom facing (A) held in place by 2 screws (B). 2. Unscrew the 4 wing nuts (D) holding the blower support plate (C). Take the assembly out. Destination 1.5 Insert Installation and Operation Manual... - Page 51 3. Remove the 2 wing nuts (D) and washers (F) holding the blower (E) in place. 4. Disconnect the wires (G) and (H). Destination 1.5 Insert Installation and Operation Manual...
- Page 52 Electric Diagram Destination 1.5 Insert Installation and Operation Manual...
-
Page 53: Appendix 5: Installation Of Secondary Air Tubes And Baffle
Appendix 5: Installation of Secondary Air Tubes and Baffle PIÈCES AMOVIBLES Secondary air tube (x3) C-cast baffle (x2) Baffle insulation (x1) Baffle insulation weight (x1) 1. Remove from the firebox the hatched bricks (9) as shown in the diagram. Destination 1.5 Insert Installation and Operation Manual... - Page 54 Repeat steps 2 and 3 for the remaining tubes. Put back the bricks in the same place. To remove the tubes use the above steps in reverse order. Destination 1.5 Insert Installation and Operation Manual...
- Page 55 The air tubes are identified for placement as follows: Model Type of tube Destination 1.5 insert Front ► 42 holes of 0.141" Middle ► 42 holes of 0.141" Rear ► 42 holes of 0.141" Destination 1.5 Insert Installation and Operation Manual...
-
Page 56: Appendix 6: Removal Instructions
To remove the backing plate (C), unscrew the 4 screws holding the backing plate to the insert. Unscrew the screws securing the 45° elbow to the insert’s flue outlet (see Section 9.5). Remove the insert from the fireplace opening to perform necessary work. Destination 1.5 Insert Installation and Operation Manual... -
Page 57: Appendix 7: Exploded Diagram And Parts List
Appendix 7: Exploded Diagram and Parts List Destination 1.5 Insert Installation and Operation Manual... - Page 58 1 28 30185 17/64" "AA" TYPE WASHER 2 29 PL66793 LATCH SPACER 1 30 PL67515 LATCH SUPPORT 1 31 30026 THREAD CUTTING SCREW 10‐24 F 5/8" HEX WASHER HEAD 2 32 30093 BOLT 1/4‐20 X 3/4" HEX GRADE 5 3 33 SE66795 DOOR HANDLE ASSEMBLY 1 34 30802 SHOWLDER SCREW #10‐24 X 3/8" 2 35 30804 SPRING 3/8'' OUTSIDE DIA. X 4 1/2'' LONG 1 Destination 1.5 Insert Installation and Operation Manual...
- Page 59 2 56 21413 C‐CAST BAFFLE 6 1/16'' X 20 1/2'' X 1 1/4'' 2 57 21411 BAFFLE INSULATION 3'' X 21 1/2'' X 1/2'' 1 58 PL34026 BAFFLE INSULATION WEIGHT 1 59 PL66810 BAFFLE SUPPORT 2 60 30029 CUTTING THREAD SCREW 10‐24 TYPE "F" X 3/8" HEX WASHER 8 61 21409 TOP INSULATION 7 1/4 '' X 21 3/8'' X 1/2'' 1 62 PL66812 TOP SUPPORT 1 63 21408 TOP REAR INSULATION 6 3/8'' X 10 11/16'' X 1/2'' ‐ R 2 7/8'' 2 Destination 1.5 Insert Installation and Operation Manual...
-
Page 60: Enerzone Limited Lifetime Warranty
Paint (peeling), gaskets, insulation, firebrick, and ceramic fibre 1 year blankets. *Pictures required Shall your unit or a components be defective, contact immediately your ENERZONE dealer. Prior to your call make sure you have the following information necessary to your warranty claim treatment: ...
