Enerzone Solution 2.5ZC Installation Instructions Manual

Hide thumbs Also See for Solution 2.5ZC:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operation & Installation Manual
MODEL ENERZONE SOLUTION 2.5ZC

Installation Instructions

This installation manual will help you obtain a safe, efficient, dependable installation for your fireplace and
chimney system. Please read and understand these installation instructions before beginning your installation.
CAUTION: Do not attempt to modify or alter the construction of the fireplace or its components. Any
modification or alteration of construction may void the warranty, listings and approvals of this system. In that
case, Stove Builder International (SBI) will not be responsible for damages. Install the fireplace only as
described in these instructions.
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
250, de Copenhague, Saint-Augustin-de-Desmaures (Quebec), Canada G3A 2H3
This manual is available for free download on the manufacturer's web site. It is a copyrighted
document. Re-sale is strictly prohibited. The manufacturer may update this manual from time to
time and cannot be responsible for problems, injuries, or damages arising out of the use of
information contained in any manual obtained from unauthorized sources.
Printed in Canada
Manufactured by:
STOVE BUILDER INTERNATIONAL INC.
Tel: (418) 878-3040 Fax: (418) 878-3001
Listed to standards
ULC-S610 and UL-127
45181A
18-04-2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Solution 2.5ZC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enerzone Solution 2.5ZC

Summary of Contents for Enerzone Solution 2.5ZC

  • Page 1: Installation Instructions

    MODEL ENERZONE SOLUTION 2.5ZC Installation Instructions This installation manual will help you obtain a safe, efficient, dependable installation for your fireplace and chimney system. Please read and understand these installation instructions before beginning your installation. CAUTION: Do not attempt to modify or alter the construction of the fireplace or its components. Any modification or alteration of construction may void the warranty, listings and approvals of this system.

  • Page 2: Table Of Contents

      2.1.1 Parts Required ........................3     2.1.2 Additional Equipment (optional) ..................3     OPERATING THE ENERZONE SOLUTION 2.5ZC ............4     2.2.1 Fuel ............................ 4     2.2.2 The use of manufactured logs .................... 4  ...
  • Page 3 OPTIONS ........................ 48       APPENDIX ......................49   SPECIFICATIONS ......................49     CLEARANCE TO COMBUSTIBLES ................49     THERMAL CHARACTERISTICS OF COMMON FLOOR PROTECTION   MATERIALS* ..........................50   ENERZONE LIMITED LIFETIME WARRANTY ..............53  ...

  • Page 4: Safety Rules For Operating Your Fireplace

    SAFETY RULES FOR OPERATING YOUR FIREPLACE  Use only an Enerzone glass door, specifically designed for the model ENERZONE SOLUTION 2.5ZC.  We recommend that our wood burning hearth products be installed and serviced by professionals who are certified in the United States by NFI (National Fireplace ®...
  • Page 5 To receive full warranty coverage, you will need to show evidence of the date you purchased your unit. Keep your sales invoice. We also recommend that you register your warranty online at http://enerzone-intl.com/warranty-registration.aspx Registering your warranty online will help us track rapidly the information we need on your unit.

  • Page 6: The Fireplace

    2.  The ENERZONE SOLUTION 2.5ZC is not intended for use with a gas log. Failure to follow these instructions will void the certification and the warranty of the fireplace and may result in an unsafe installation.

  • Page 7: Operating The Enerzone Solution 2.5Zc

    Decorative fireplaces generally have larger, cooler, and less air-tight fireboxes. Your ENERZONE SOLUTION 2.5ZC, on the other hand, has a smaller, completely sealed firebox which attains much higher temperatures. It is therefore not designed to support excessive heat caused by the addition of chemicals in manufactured logs.

  • Page 8: First Fires

    Your ENERZONE SOLUTION 2.5ZC fireplace will work best if a thick bed of hot embers is maintained in the bottom of the firebox, and a minimum of two large pieces of seasoned fuel are added.

  • Page 9: Primary Air

    2.2.6 Primary Air There is no flue damper in the ENERZONE SOLUTION 2.5ZC. As in common with air tight stoves, the combustion air control sets the flow of air entering the firebox. This allows for a more precise control of the fire.

  • Page 10: Combustion Settings

    By this method, the ENERZONE SOLUTION 2.5ZC can produce up to 75,000 BTU of heat per hour. However, it will be necessary to reload with wood every one or two hours. This is the least efficient method of burning the ENERZONE SOLUTION 2.5ZC.

  • Page 11: Smoking  Causes And Troubleshooting

    As the fire burns, air goes up the chimney. This air must be replaced through leakage into the house or through the fresh air kit. When operating the ENERZONE SOLUTION 2.5ZC, open a nearby window temporarily to check if there is adequate air supply replacement.

  • Page 12: Maintaining Your Enerzone Solution 2.5Zc

    F. Do not allow the wood to smoulder or burn without flame, since this will produce excessive creosote in the unit. MAINTAINING YOUR ENERZONE SOLUTION 2.5ZC 2.3.1 Creosote – Formation and Need for Removal When wood is burned slowly without a flame, it produces tar and other organic vapours which combine with expelled moisture to form creosote.

  • Page 13: Fire Baffle Removal Prior To Cleaning The Chimney

    2.3.3 Fire Baffle Removal Prior to Cleaning the Chimney Before starting to clean your chimney, we recommend that you remove the fire baffle to avoid creosote dust collection on top of the baffle. Follow the steps below to remove the fire baffle: 1.

  • Page 14: Plated Finish Maintenance

    2.3.5 Plated Finish Maintenance Use a metal polish and a soft cloth to clean the plated finishes. Do not use abrasives such as steel wool, steel pads or an abrasive cleaner for they may scratch the finish. 2.3.6 Disposal of Ashes Do not attempt to clean the fireplace when the unit is hot.

  • Page 15: Glass Care - Replacement

    2.3.8 Glass Care – Replacement The two glasses used in the ENERZONE SOLUTION 2.5ZC are 5 mm thick and have the same dimension of 13.188" H x 11.875" W. They are tested to reach temperatures up to 1400º F. If a glass breaks, it must be replaced with one having the same specification.

  • Page 16: Glass Care - Cleaning

    2.3.9 Glass Care – Cleaning The ENERZONE SOLUTION 2.5ZC is designed to keep the glass clean under normal operating conditions. If the ENERZONE SOLUTION 2.5ZC is operated continuously with the combustion air controls closed, the glass will tend to get dirty unless the fuel, firebox and glass are maintained at higher temperatures.

  • Page 17: Fireplace Installation

    26". Note the floor construction and consult your local building code to determine if additional support is needed. C. The ENERZONE SOLUTION 2.5ZC may be installed directly on the floor or on a raised base (for proper guidelines, refer to “Heart Extension Requirements”) and a minimum of 7 feet (2.15 m) measured from the base of the appliance to the ceiling is required.

  • Page 18: Heart Extension Requirements

    2.4.2 Heart Extension Requirements The hearth extension floor area must extend at least 16" (40 cm) in front of the hearth and at least 8" (20 cm) on each side of the door opening (see figure 7). The joint between the hearth extension and the fireplace hearth needs to be made of non-combustible material such as sheet metal (not included) as shown on figure 8.
  • Page 19 When the fireplace is installed directly on the floor, a noncombustible floor protection in front of the unit must be installed and have an R value insulation equal to or greater than 1.00. The use of an R value is convenient when more than one material is going to be used in the hearth extension to cover the combustible surface.
  • Page 20 2.4.2.2 How to eliminate the need of a R value It is however possible to eliminate the R value by elevating the unit from 4'' above the floor (see Figure 9), but the joint between the extension of the hearth and the fireplace must be protected by a non-combustible material.

  • Page 21: Framing, Facing, Mantel, And Combustible Shelf

    2.4.3 Framing, Facing, Mantel, and Combustible Shelf  Framing The construction of the framing, facing, and mantel must be in accordance with the standards and the following illustrations (figures 10 to 14): A. Frame the fireplace using 2" × 3" (5 cm x 8 cm) or heavier lumber. WARNING: COMBUSTIBLE FRAMING MATERIAL CANNOT BE USED IN THE SPACE DIRECTLY ABOVE THE FIREPLACE, EXCEPT FOR THE STUDS ABOVE THE FACING THAT SUPPORT THE FACING MATERIAL AND...
  • Page 22 Figure 10 Figure 11...
  • Page 23 Figure 12 Figure 13...
  • Page 24 Figure 14...

  • Page 25: Insulated Chase Construction

    INSULATED CHASE CONSTRUCTION Figure 15  Facing 1. Materials directly in contact with the faceplate of the fireplace, especially the vertical and horizontal surround, must be non-combustible and have the minimal dimensions as shown on figure 16. 2. Non-combustible materials such as brick, stone or ceramic tile may project in front of and onto the fireplace decorative frame.
  • Page 26 Figure 16...

  • Page 27: Combustible Shelf

     Combustible shelf To install any combustible shelf, refer to figure 17 for a safe installation. For example, a shelf with a 6’’ depth (152 mm) must be installed at least 50" (127 cm) above the base of the fireplace. Different shelf dimensions are listed in figure 17 in order to facilitate installation. However, the minimum depth of the shelf is 6"...
  • Page 28 Figure 18...

  • Page 29: Blower Connection

    2.4.4 Blower connection The fan will come on as soon as the fireplace reaches its minimum start temperature. Have the wiring installed by a qualified electrician. Connect the wires from the power outlet to the terminal block, making sure that the white wire matches the white wire on the terminal. Connect the black wire with the black wire of the terminal block.

  • Page 30: Hot Air Ducting Installation

    HOT AIR DUCTING INSTALLATION Different hot air ducting systems can be installed with the ENERZONE SOLUTION 2.5ZC:  Gravity kit  Forced air kit 2.5.1 Gravity Kit The kit includes:  2 x hot air outlets (grilles and frames);  2 x 90 elbows with brackets;...
  • Page 31 The hot air grilles can be installed in the same room as the fireplace, or one or both of the grilles can be installed in adjacent or upper rooms. Installing the ducts at different elevations will tend to exhaust more heat out of the higher grilles (figure 23). Figure 22 Figure 23...

  • Page 32: Central Forced Air Kit (Not Tested Under Epa Certification)

    2.5.2 Central Forced Air Kit (Not tested under EPA certification) The knock-outs provided on the back and on the sides of the ENERZONE SOLUTION 2.5ZC allow the connection of insulated flexible pipe which enables you to heat adjacent rooms up to 50 feet from the fireplace (see figure 26).
  • Page 33 D) Attach a flexible pipe to the fan’s air outlet and route the flexible pipe to the chosen location. The ducting system can be installed either in an upper room or in a lower room; E) At that point, the flexible pipe can be attached to any air distribution grille. F) Make the electrical connections to the PC Board as explained with the forced air kit owner’s manual.

  • Page 34: Fresh Air Kit (Optional)

    FRESH AIR KIT (OPTIONAL) During operation, the fireplace requires fresh air for combustion and draws air out of the house. It may starve other fuel burning appliances such as gas or oil furnaces. As well, exhaust fans may compete for air, causing negative pressure in the house, resulting in smoke entering the house from the fireplace.
  • Page 35 OUTSIDE AIR FRESH AIR INTAKE CONNECTION TO THE FIRE PLACE FIREPLACE CONNECTION ALUMINUM OUTSIDE TAPE INTAKE FIREPLACE ALUMINUM TAPE PLASTIC COVER 3" FLEXIBLE PIPE PLASTIC COVER FLEXIBLE PIPE SCREW OPENING FACING DOWN INSULATION ALUMINUM INSULATION WALL ALUMINUM TAPE TAPE Figure 27 Figure 28 1) Remove the bottom louver 2) Seal the room air intake located on the right side...

  • Page 36: Door Overlay Installation

    3 OPTIONS Figure 30 Figure 31 Figure 33 Figure 32 DOOR OVERLAY INSTALLATION In order to install the door overlay, simply put the overlay on the door frame. Then, pass the 4 bolts through the holes shown in figure 34. Finally, secure the door overlay in place using the 4 nuts.

  • Page 37: Door Alignment

    DOOR ALIGNMENT To adjust the door positioning and spacing, loosen the hinge screw and pivot the hinge until the door is in the correct position. To tilt the door, lock in place one of the two hinges and pivot the other. The door will tilt to one side or the other depending on the direction the hinge is pivoted.

  • Page 38: Optional Fire Screen Installation (Ac01308)

    OPTIONAL FIRE SCREEN INSTALLATION (AC01308) Open the doors. Hold the fire screen by the two handles and bring it close to the door opening. Lean the upper part of the fire screen against the top door opening making sure to insert the top fire screen bracket behind primary...

  • Page 39: The Chimney

    Installations, which are located on lower floors in the house, such as in a basement, in combination with outside chimney, are especially prone to flow reversal. 2. The ENERZONE SOLUTION 2.5ZC is listed only with chimney systems described in table 2.

  • Page 40: Chimney Installation Instructions

    CHIMNEY INSTALLATION INSTRUCTIONS Cut and frame the holes in the ceiling, floor and roof where the chimney will pass and install rafter protectors (see figure 37). Use a plumb bob to line up the center of the holes. Make sure that the size of the floor and ceiling holes are in accordance with the chimney manufacturer’s instructions.
  • Page 41 EXAMPLE OF TYPICAL CHIMNEY INSTALLATION Figure 38...
  • Page 42 When you build a combustible chase enclosure for chimney sections above the roof, refer to the chimney manufacturer for clearances to combustible materials. Figure 39 – Example of a combustible chase enclosure installation above the roof...

  • Page 43: Offset Chimney Installation

    OFFSET CHIMNEY INSTALLATION The minimum system height when using elbows is: Fireplace model ENERZONE SOLUTION 2.5ZC Chimney model All models Vertical installation 15 ft. (4.6 m) Two (2) elbows 15 ft. (4.6 m) Four (4) elbows 17 ft. (5.2 m)
  • Page 44 Figure 40 Figure 41...
  • Page 45 TABLE 2 - LISTED CHIMNEYS FOR YOUR ENERZONE SOLUTION 2.5ZC CHIMNEY BRAND TYPE INNER DIAMETER MANUFACTURER Selkirk Ultra-Temp (UT) 1” Solid Pack 6" (15 cm) Selkirk Super Pro (SPR) 1” Solid Pack 6" (15 cm) Selkirk Super Vent (JSC) 1” Solid Pack 6"...
  • Page 46 Inner diameter 6″ Inner diameter 7″ Reference Parts required. (The numbers in Figure brackets are the parts numbers 1″ 2″ 1″ 2″ used by Security Chimneys) insulation insulation insulation insulation (ASHT+) (S2100+) (ASHT+) (S2100+) Anchor Plate (6SP) Anchor Plate (6XSP) Screws 6″...

  • Page 47: Angled Wall Radiation Shield

    ANGLED WALL RADIATION SHIELD When passing through a combustible wall with the chimney at a 30 or 45 angle (30 or 45 in Canada and 30 only in the USA), an angled firestop or wall radiation shield provided by the chimney manufacturer must be installed.

  • Page 48: Chimney Support Installation

    CHIMNEY SUPPORT INSTALLATION Universal Roof Support This support has three possible uses: 1. It must be used on a roof to support the chimney. 2. It may be used on a floor, ceiling or roof above an offset to support the chimney above the offset.

  • Page 49: Chimney Chase And Multiple Terminations

    CHIMNEY CHASE AND MULTIPLE TERMINATIONS For the purpose of this manual, a chimney chase is considered a part of the chimney system rather than part of a building. The termination must be placed a minimum of 18" (460 mm) above the chase.

  • Page 50: Installation Instructions For Masonry Application

    INSTALLATION INSTRUCTIONS FOR MASONRY APPLICATION WARNING: Before starting the installation, the masonry chimney must be inspected by a qualified sweep. The following requirements must be respected: 1. The chimney must be absolutely clear of any soot residue or creosote. Check for cracks, loose or missing bricks that could inhibit correct installation of the liner.

  • Page 51: Options

    OPTIONS Gravity kit: Part No.: Includes: one deflector, two 90 elbows, and two outlet grilles and frames, #AC01309 Central forced air kit: Includes: one blower, one 5" flex adapter, 3 pipe clamps, and one control box with heat sensor and PC Board. #AC01310 Outside air kit Includes: one 3"...

  • Page 52: Appendix

    APPENDIX SPECIFICATIONS Weight: 385 lbs Height: 38" Width: 36.75" Depth: 26" Maximum recommended heating area: 500 to 2,100 square feet (with forced air kit) Heating capacity* – BTU/hr., EPA test wood: 30,500 Heating capacity* – BTU/hr., seasoned cordwood: 75,000 Optimum efficiency: 77% *Why is the BTU indicated on the EPA label smaller than the one advertised? You will notice a difference between the BTU output as indicated on the unit’s white EPA label affixed to the glass and the BTU as advertised on our web site and/or product literature.

  • Page 53: Thermal Characteristics Of Common Floor Protection Materials

    THERMAL CHARACTERISTICS OF COMMON FLOOR PROTECTION MATERIALS* MATERIAL CONDUCTIVITY RESISTANCE (R) PER INCH (k) PER INCH THICKNESS Micore® 160 0.39 2.54 Micore® 300 0.49 2.06 Durock® 1.92 0.52 Hardibacker® 1.95 0.51 Hardibacker® 500 0.44 Wonderboard® 3.23 0.31 Cement mortar 5.00 Common brick 5.00 Face brick...
  • Page 54 Exploded view for replacement parts...
  • Page 55 List of replacement parts 1  AC01300  BLACK CAST IRON DOOR OVERLAY  1  1  AC01301  GOLD PLATED CAST IRON DOOR OVERLAY  1  1  AC01302  BRUSHED NICKEL CAST IRON DOOR OVERLAY  1  2  SE24150  BOTTOM GRILLE ASSY.  1  3  SE45181  OWNER MANUEL ENERZONE 2.5ZC  1  4  PL63866  AIR CONTROL MECHANISM  1  5  30187  ZINC WASHER ID 17/64" X OD 1/2"  1  6  30185  17/64" "AA" TYPE WASHER  1  7  30060  THREAD‐CUTTING SCREW 1/4‐20 X 1/2" F HEX STEEL SLOT WASHER C102 ZINC  1 ...

  • Page 56: Enerzone Limited Lifetime Warranty

    Paint (peeling), gaskets, insulation, firebrick, and ceramic fibre blankets. 1 year *Pictures required Shall your unit or a components be defective, contact immediately your ENERZONE dealer. Prior to your call make sure you have the following information necessary to your warranty claim treatment: ...
