Installation
and Operation
Manual
SOLUTION 2.5ZC II
(EB00059)
US Environmental Protection Agency
Safety tested according to ULC S610,
phase II certified wood fireplace
UL 127 standards by an accredited
compliant with 2020 cord wood standard
laboratory.
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN
LOCAL AREA.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD FIREPLACE. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
46128A
2023-08-01
Advertisement
Table of Contents
Related Manuals for Enerzone SOLUTION 2.5ZC II
Summary of Contents for Enerzone SOLUTION 2.5ZC II
- Page 1 Installation and Operation Manual SOLUTION 2.5ZC II (EB00059) US Environmental Protection Agency Safety tested according to ULC S610, phase II certified wood fireplace UL 127 standards by an accredited compliant with 2020 cord wood standard laboratory. CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN LOCAL AREA.
- Page 3 It is also highly recommended to register the warranty online at https://www.enerzone-intl.com/en/warranty/warranty-registration/ Registering the warranty will help to quickly find the information needed on the unit. Installation and Operation Manual - Solution 2.5ZC II Page 3...
-
Page 4: Table Of Contents
7.1 Safety ...........................31 7.2 Standards ........................31 8. Fireplace Installation ......................32 8.1 Standoff Installation ......................32 8.2 Optional Carrying Handles ....................32 8.3 Location ........................32 8.4 Clearances to Combustibles ....................32 8.5 Framing Construction ......................33 Page 4 Installation and Operation Manual - Solution 2.5ZC II... - Page 5 Appendix 8: Secondary Air Tubes and Baffle Installation ............67 Appendix 9: Blower Replacement .................... 68 Appendix 10: Exploded Diagram and Parts List ..............70 ENERZONE Limited Lifetime Warranty ..................73 Dealer: Installer: Phone Number: Serial Number: Installation and Operation Manual - Solution 2.5ZC II Page 5...
- Page 6 CERTIFICATION PLATE Page 6 Installation and Operation Manual - Solution 2.5ZC II...
-
Page 7: Part A - Operation And Maintenance
WARNING This product can expose you to chemicals including carbon monoxide, which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to www.P65warnings.ca.gov/ Installation and Operation Manual - Solution 2.5ZC II Page 7... -
Page 8: General Information
This appliance is officially tested and certified by an independent agency. Tested and certified in compliance with CFR 40 part 60, subpart AAA, section 60.534(a)(1(ii) and ASTM E3053-17. Carbon monoxide. Page 8 Installation and Operation Manual - Solution 2.5ZC II... -
Page 9: Specifications
CAN/CSA- Z240 MH standard. Tested and certified in compliance with CFR 40 part 60, subpart AAA, section 60.534(a)(1(ii) and ASTM E3053-17. Installation and Operation Manual - Solution 2.5ZC II Page 9... -
Page 10: Dimensions
343mm 268mm 25 3/8" 11 1/8" 645mm 284mm Figure 2: Front view Figure 3: Front view - Door opening G : Opening for gravity hot air distribution kit (ø 8"). Page 10 Installation and Operation Manual - Solution 2.5ZC II... - Page 11 933mm 4 1/2" 116mm 12 1/4" 310mm Figure 6: Bottom view F : Opening for forced air distribution kit (ø 6"). A : Opening for fresh air intake (ø 4"). Installation and Operation Manual - Solution 2.5ZC II Page 11...
- Page 12 Figure 7: Combustion chamber - Top view 1/2" 13mm 1" 25mm 12 1/8" 307mm 12 7/8" 326mm Figure 8: Left view - Faceplate projection Figure 9: Combustion chamber - Side view Page 12 Installation and Operation Manual - Solution 2.5ZC II...
-
Page 13: Epa Certification Loading
Leave the primary air control open for approximately 5 minutes and then close the primary air control halfway. After another 5 minutes, close the air control completely for the low burn rate and 3/8” open for the medium burn rate. Installation and Operation Manual - Solution 2.5ZC II Page 13... -
Page 14: Materials
Although the fireplace may be able to heat the main living areas of the house to an adequate temperature, it is strongly recommended to also have a conventional oil, gas or electric heating system to provide backup heating. Page 14 Installation and Operation Manual - Solution 2.5ZC II... -
Page 15: Emissions And Efficiency
The tree species the firewood is produced from is less important than its moisture content. The main difference in firewood from various tree species is the density of the wood. Hardwoods are denser than softwoods. Installation and Operation Manual - Solution 2.5ZC II Page 15... -
Page 16: Log Length
Do not poke or stir the logs while they are burning. Use only logs that meet the requirements of ULC/ORD C127 M1990 for composite logs. Refer to package cautions and warnings before using logs. Page 16 Installation and Operation Manual - Solution 2.5ZC II... -
Page 17: Drying Time
− Two pieces of wood struck together sounds hollow; − The face of a fresh cut feels warm and dry; − The moisture content read by a moisture meter is between 15% to 20%. Installation and Operation Manual - Solution 2.5ZC II Page 17... -
Page 18: Operating The Fireplace
(C) fully to the left or by changing the mode. OFF: To completely turn off the blower, turn the rheostat button (C) counterclockwise until the blower stops. Page 18 Installation and Operation Manual - Solution 2.5ZC II... -
Page 19: Burning Wood Efficiently
Leave enough space between the logs for good air circulation. The log length recommended for this fireplace is 16 in. Installation and Operation Manual - Solution 2.5ZC II Page 19... -
Page 20: Combustion Cycles
Wood heating with a space heater is very different than other forms of heating. There will be temperature variations in different parts of the house and there will be temperature variations Page 20 Installation and Operation Manual - Solution 2.5ZC II... - Page 21 This is especially true if the chimney is on the outside wall of the house. If the door must be opened while the fire is flaming, fully open air control for a few minutes then open the door slowly. Installation and Operation Manual - Solution 2.5ZC II Page 21...
-
Page 22: Rekindling A Fire
No other waste should be placed in this container. NEVER STORE ASHES INDOORS OR IN A NON-METALLIC CONTAINER OR ON A WOODEN DECK. CENDRES ASHES Page 22 Installation and Operation Manual - Solution 2.5ZC II... -
Page 23: Air Intake Control
Before reducing the air intake, the load will have to burn at full heat for long enough for charring the surface of the logs. The flame must be bright before letting the fire burn by itself. Installation and Operation Manual - Solution 2.5ZC II Page 23... - Page 24 East-west loads allow a limited amount of wood since too many logs could cause them to fall on the glass. East-west loads, placed in a compact way, take a long time before breaking down. They are excellent for low-intensity, long-lasting fires in relatively mild weather. Page 24 Installation and Operation Manual - Solution 2.5ZC II...
-
Page 25: Maintenance
The deposits that form on the glass are the best indication of the fuel quality and success in properly using the fireplace. These stains can be cleaned with a special wood stove glass cleaner. Do not use abrasive products to clean the glass. Installation and Operation Manual - Solution 2.5ZC II Page 25... - Page 26 Peel off more of the backing and rotate the glass. The gasket must not be stretched during installation. Cut the gasket to the required length. Pinch the gasket onto the glass in a U-shape, all around the glass. Page 26 Installation and Operation Manual - Solution 2.5ZC II...
-
Page 27: Door
The door seal may be improved with a simple latch mechanism adjustment on the right door: Remove the split pin by pulling and turning it using pliers. Turn the handle one counterclockwise turn to increase pressure. Reinstall the split pin with a small hammer. Installation and Operation Manual - Solution 2.5ZC II Page 27... - Page 28 Remove the old gasket (L) from the door. Use a screwdriver to scrape the old gasket adhesive from the door gasket groove. Also remove the screws (I), the retainers (J) and the door middle gasket (K). Page 28 Installation and Operation Manual - Solution 2.5ZC II...
-
Page 29: Exhaust System
Contact your local municipal or provincial fire authority for information on how to handle a chimney fire. Have a clearly understood plan to handle a chimney fire. Installation and Operation Manual - Solution 2.5ZC II Page 29... -
Page 30: Part B - Installation
Additional Equipment (optional) • Forced air distribution kit; • Traditional or modern gravity hot air distribution kit; • Fresh air kit; • Fire Screen; • Heat shield for combustible shelf. Page 30 Installation and Operation Manual - Solution 2.5ZC II... -
Page 31: Safety Information And Standards
This fireplace is not approved for use with a so-called “positive flue connection” to the clay tile of a masonry chimney. Installation and Operation Manual - Solution 2.5ZC II Page 31... -
Page 32: Fireplace Installation
ULC S610 (Canada) and UL127 (U.S.A.). When the fireplace is installed so that its surfaces are at or beyond the minimum clearances specified, combustible surfaces will not overheat under normal and even abnormal operating conditions. Page 32 Installation and Operation Manual - Solution 2.5ZC II... -
Page 33: Framing Construction
The standoffs can be installed either flush with the fireplace or setback of ½" depending on the thickness of the finishing material used. 1/2" 13mm 0" Installation and Operation Manual - Solution 2.5ZC II Page 33... - Page 34 Inside the chase, around the fireplace, insulation should be covered with drywall panels or any other finishing material except where non- combustible material is required. 80" 2032mm 40 5/8" 1032mm VARIABLE Page 34 Installation and Operation Manual - Solution 2.5ZC II...
- Page 35 Smaller dimensions can be used depending on the size and type of duct as well as the configuration of the installation. HVAC duct, as per ULC S110 or UL 181, class 0 or class 1, must withstand temperatures up to 250oF. Installation and Operation Manual - Solution 2.5ZC II Page 35...
- Page 36 Smaller dimensions can be used depending on the size and type of duct as well as the configuration of the installation. HVAC duct, as per ULC S110 or UL 181, class 0 or class 1, must withstand temperatures up to 250oF. Page 36 Installation and Operation Manual - Solution 2.5ZC II...
-
Page 37: Hearth Extension Construction
It is recommended to make the sheet metal in one piece. A clearance of 80" (2.03 m) (F) between the base of the fireplace and the ceiling must be respected. Installation and Operation Manual - Solution 2.5ZC II Page 37... - Page 38 Alternatives approved by the local building code may also be used. Do not leave carpets under the floor protection. Page 38 Installation and Operation Manual - Solution 2.5ZC II...
- Page 39 Total R value = .8 + 0.52 = 1.32 Information as reported by manufacturers and other resources Horizontal still air can’t be «stack» to accumulate R-values; each layer must be separated with another non-combustible material. Installation and Operation Manual - Solution 2.5ZC II Page 39...
-
Page 40: Facing
52" (1,32 m) to the depth of the shelf to find the safe position of the shelf. The height (A) should always be 80" (2.03 m) from the base of the fireplace. 48" 1219mm Page 40 Installation and Operation Manual - Solution 2.5ZC II... -
Page 41: Heat Shield For Combustible Shelf
Outside chimneys will lead to cold back drafting when there is no fire in the fireplace, slow kindling of new fires, and smoke roll-out when the door is open for loading. Installation and Operation Manual - Solution 2.5ZC II Page 41... -
Page 42: Supply Of Combustion Air
If only the minimum height of the chimney system is installed, the operating conditions must be optimal (interior chimney, minimum height of 18" (457 mm) before any deviation, etc.). Page 42 Installation and Operation Manual - Solution 2.5ZC II... - Page 43 • A clearance of 2" (50 mm) between the chimney and any combustible material is required. This space must remain free, without insulation or other combustible material.The parts of the chimney that pass into inhabited spaces must be enclosed in an enclosure. Installation and Operation Manual - Solution 2.5ZC II Page 43...
- Page 44 MUST EXCEED THE TOP OF THE FLASHING CONE BY AT LEAST 12 INCHES (30 CM). THE FLASHING MUST HAVE A MINIMUM HEIGHT OF 6 INCHES (15.25CM). THE TOP OF THE ENCLOSURE MUST BE MADE OF NON-COMBUSTIBLE MATERIALS. Page 44 Installation and Operation Manual - Solution 2.5ZC II...
- Page 45 • If the male anchor plate nozzle exceeds 2" (50 mm) in length (A), it must be cut above the lifting hooks welded inside the flue outlet so that it is sitting perfectly on the top of the fireplace. Installation and Operation Manual - Solution 2.5ZC II Page 45...
- Page 46 Place the storm collar (F) on the roof flashing and tighten it with the bolt. Seal the joint between the storm collar and the chimney, using silicone sealant. Install the chimney cap (G). Page 46 Installation and Operation Manual - Solution 2.5ZC II...
- Page 47 Before starting the installation, the masonry chimney should be inspected for cracks, crumbling mortar, creosote layers, obstructions or other signs of deterioration. If signs of deterioration are noted, the chimney should be repaired and cleaned before installation. Installation and Operation Manual - Solution 2.5ZC II Page 47...
-
Page 48: Angled Wall Pass-Thru Installation
• a floor, ceiling, or roof over an offset to support the chimney or; • as additional support. Always follow the manufacturer’s instructions for the maximum chimney height that can be supported by the support. Page 48 Installation and Operation Manual - Solution 2.5ZC II... -
Page 49: Approved Chimneys
AC Triple Wall 6" (15 cm) Metal Fab Temp Guard 1" Solid Pack 6" (15 cm) American Metal AC Triple Wall 6" (15 cm) American Metal AC Triple Wall 6" (15 cm) Installation and Operation Manual - Solution 2.5ZC II Page 49... - Page 50 Rafter protectors, at the roof level, must be installed with this unit, if the chimney is enclosed at the attic level. Rafter protectors must be made of 22 ga or more galvanized steel and must have at least the dimension presented on the following diagram: Page 50 Installation and Operation Manual - Solution 2.5ZC II...
-
Page 51: Appendix 1: Faceplate Installation
A faceplate must be installed on this fireplace. Two choices of faceplate are offered. See the faceplate installation manual for more details. Figure 10: Traditional style faceplate Figure 11: Rustic style faceplate Installation and Operation Manual - Solution 2.5ZC II Page 51... -
Page 52: Appendix 2: Optional Fresh Air Intake Installation
The fresh air intake can be installed in two different locations on the fireplace. On the right side (1) of the fireplace (the most common) or underneath the fireplace (2). Page 52 Installation and Operation Manual - Solution 2.5ZC II... - Page 53 Using a screwdriver, secure with 4 screws (G) found in the user manual. Installing the plate will make the air intake housing airtight and prevent cold air from entering the fireplace when not in use. Installation and Operation Manual - Solution 2.5ZC II Page 53...
- Page 54 MIN 10 pi MAX 3 pi It is strongly recommended to install a mechanical shutter that closes the outside air inlet when the fireplace is not in use. Page 54 Installation and Operation Manual - Solution 2.5ZC II...
-
Page 55: Appendix 3: Optional Traditional Gravity Hot Air Distribution Kit Installation
208mm 25mm TYP. TYP. 15 1/8" 383mm 5/8" 14mm Dimensions of hot air outlet decorative grille with elbow 10" 254mm TYP. 5/8" 2" 14mm 38mm MIN. MAX. 7/8" 23mm TYP. Installation and Operation Manual - Solution 2.5ZC II Page 55... - Page 56 There must be a clearance of at least 2" (50 mm) between the ducts and the firestop. 13" X 13" 330mm X 330mm 12" MIN. 13" X 13" 330mm X 330mm 12" MIN. Page 56 Installation and Operation Manual - Solution 2.5ZC II...
- Page 57 Screw 6 steel brackets (D) with 6 screws (E) onto the top of the fireplace (3 per duct). Insert the ducts (G) (not supplied) into each opening and screw in place in the brackets (D) with 6 self- drilling screws (F). Installation and Operation Manual - Solution 2.5ZC II Page 57...
- Page 58 Screw the frame (B) to the outlet of the elbow (C) with 3 self-drilling screws in each. Attach the decorative grilles (A) to the frames with screws. Page 58 Installation and Operation Manual - Solution 2.5ZC II...
-
Page 59: Appendix 4: Optional Modern Gravity Hot Air Distribution Kit Installation
Dimensions of heat distribution box 32 1/8" 816mm 35 1/8" 892mm 1 1/2" 39mm TYP. 15 1/8" 383mm 2 1/2" 62mm 5 3/4" 147mm 8" 203mm (2) Installation and Operation Manual - Solution 2.5ZC II Page 59... - Page 60 Dimensions of assembled heat distribution box and adjustable decorative plate 1" 25mm 0" 11/16" 17mm MIN. MAX. 35 1/8" 892mm Dimensions of telescoping section 36 1/8" 918mm 21 3/8" 543mm Page 60 Installation and Operation Manual - Solution 2.5ZC II...
- Page 61 (same as the one used for a class A chimney) must be installed in the opening of the wall or floor. There must be a clearance of at least 2" (50 mm) between the ducts and the firestop. 13" X 13" 330mm X 330mm 12" MIN. 12" MIN. Installation and Operation Manual - Solution 2.5ZC II Page 61...
- Page 62 Secure 2 anchor plates (E) with 8 screws provided (F) on top of the fireplace (4 for each anchor plate). Insert the telescoping section (D) into each anchor plate and secure it with 6 other self- tapping screws provided (G). Page 62 Installation and Operation Manual - Solution 2.5ZC II...
- Page 63 (C), press it against the non-combustible material and secure with 4 screws into the heat distribution box. Set the decorative plate (A) to the adjustable frame (B). Installation and Operation Manual - Solution 2.5ZC II Page 63...
-
Page 64: Appendix 5: Optional Forced Air Distribution Kit Installation
However, this appliance has already been tested for emission with one or more convection blowers. The environmental requirements are then met efficiently. Page 64 Installation and Operation Manual - Solution 2.5ZC II... -
Page 65: Appendix 6: Optional Fire Screen Installation
Lift the fire screen upwards and push the bottom part towards the fireplace then let the fire screen rest on the bottom of the door opening. Installation and Operation Manual - Solution 2.5ZC II Page 65... -
Page 66: Appendix 7: Refractory Panels Removal
(D) holding the andiron (C). T-30 Using a power driver, remove the refractory Remove the back refractory panel (F). panel brackets (G) and the side refractory panels (I). 3/8" Page 66 Installation and Operation Manual - Solution 2.5ZC II... -
Page 67: Appendix 8: Secondary Air Tubes And Baffle Installation
Repeat steps 1 and 2 for the two front tubes. To remove the tubes use the above steps in reverse order. Note that secondary air tubes (A) can be replaced without removing the baffle board (B). Installation and Operation Manual - Solution 2.5ZC II Page 67... -
Page 68: Appendix 9: Blower Replacement
Remove the air control decorative panel (J) Remove the air control housing (L) by by removing the screws (K). pulling on it. Remove the certification plate (M). Cut the tie wrap (N). Page 68 Installation and Operation Manual - Solution 2.5ZC II... - Page 69 RHEOSTAT / RHÉOSTAT WHITE / BLANC BLACK NOIR BLACK NOIR BLACK / NOIR TERMINAL / BORNIER GREEN GROUND 2 POSITIONS ROCKER SWITCH VERT MISE À LA TERRE INTERRUPTEUR 2 POSITIONS Installation and Operation Manual - Solution 2.5ZC II Page 69...
-
Page 70: Appendix 10: Exploded Diagram And Parts List
APPENDIx 10: ExPLODED DIAGRAM AND PARTS LIST 46 45 DETAIL E DETAIL D DETAIL A DETAIL B DETAIL C Page 70 Installation and Operation Manual - Solution 2.5ZC II... - Page 71 RUSTIC STYLE LOUVERS AC01256 TRADITIONAL STYLE LOUVERS 30472 SPRING 1/2'' OUTSIDE Ø X 3''L 30767 SPRING 1/2'' OUTSIDE DIA. X 8''L AC05959 METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL Installation and Operation Manual - Solution 2.5ZC II Page 71...
- Page 72 HOT AIR GRAVITY DISTRIBUTION KIT - TRADITIONAL 49066 90° X 8" 26Ga. GALVANISED ELBOW 30640 GALVANISED BOX FOR HOT AIR GRAVITY DISTRIBUTION KIT 8" 30540 HOT AIR GRAVITY DISTRIBUTION KIT GRILL Page 72 Installation and Operation Manual - Solution 2.5ZC II...
-
Page 73: Enerzone Limited Lifetime Warranty
Labour cost and repair work to the account of the manufacturer are based on a predetermined rate schedule and must not exceed the wholesale price of the replacement part. Shall your unit or a components be defective, contact immediately your ENERZONE dealer. To accelerate processing of your warranty claim, make sure to have on hand the following information when calling:... - Page 74 NOTES :...
- Page 75 NOTES :...
- Page 76 Resale is strictly prohibited. The manufacturer may update St-Augustin-de-Desmaures (Québec), Canada this document from time to time and cannot be responsible G3A 2H3 for problems, injuries, or damages arising out of the use 418-908-8002 of information contained in any document obtained from www.enerzone-intl.com/en/ unauthorized sources. tech@sbi-international.com...
