Assigning EDID
To assign EDID to selected inputs:
1. From the inputs screen (table of inputs) on the right, select check boxes for the desired
inputs.
2. From the Available EDIDs list, select the desired EDID. The selected EDID highlights
yellow.
3. Click the button to assign EDID to the selected input or inputs.
Assign
To assign EDID to all inputs:
1.
From the EDID table, select an available EDID.
2. Click the button.
Assign All
NOTE: Checked or unchecked inputs are ignored and the EDID is assigned to all
inputs.
To match the selected inputs to the current output resolution:
This is the default setting for all inputs.
1. From the inputs table on the right, select the desired inputs.
2. In the Output Resolution section, click
Uploading EDID
1. From the Inputs screen (table of inputs) on the right, select the desired inputs.
2. Click the
Upload EDID to IN1606
3. Navigate to the desired EDID file location and select it.
4. Click the button. The EDID is assigned to the selected inputs.
Open
Saving EDID to a PC
1. From the Connected Outputs or Available EDIDs, right-click on an EDID.
2. Select
Save EDID to PC
3. Click the radio button.
Save File
4. Click the button to save the file.
OK
NOTE: Saving a factory IN1606 EDID exports an HDMI, LPCM-2Ch EDID to the PC.
IN1606 Scaling Presentation Switcher • Internal Web Pages
Match Output
button.
.
.
