CAUTION
Pinch Hazard
Installation of door panels with less than a ³⁄₈" (0.95 cm) gap
between the door panel and the adjacent cabinet increases
the risk of potential pinching.
Model 42
³⁄₈" ¹⁄₈"
Reveal
A 17⁹⁄₁₆" 17¹³⁄₁₆"
(44.61 cm) (45.24 cm)
B 23⁹⁄₁₆" 23¹³⁄₁₆"
(59.85 cm) (60.48 cm)
Grille Panel
Fully Integrated Grille Installation—Full Height Grille—
Open Soffit
⁵⁄₈
6 "
(16.83 cm)
Model 42
Reveal ³⁄₈" ¹⁄₈"
C 41¹⁄₄" 41³⁄₄"
(104.78 cm) (106.05 cm)
Standard Grille Installation—Flush Grille—
Open or Closed Soffit
1" (2.54 cm)
³⁄₄
5 "
(14.55 cm)
Model 42
³⁄₈" ¹⁄₈"
Reveal
D 41¹⁄₄" 41³⁄₄"
(104.78 cm) (106.05 cm)
E 41¹⁄₄" 41³⁄₄"
(104.78 cm) (106.05 cm)
IMPORTANT: The grille panel height, shown in the "Standard
Integrated Grille Installation—Side View" graphic, allows for an
air gap critical to refrigerator performance.
14
48
³⁄₈" ¹⁄₈"
20¹⁄₁₆" 20⁵⁄₁₆"
(50.96 cm) (51.59 cm)
27¹⁄₁₆" 27⁵⁄₁₆"
(68.74 cm) (69.37 cm)
C
Top Grille Panel
48
³⁄₈" ¹⁄₈"
47¹⁄₄" 47³⁄₄"
(120.02 cm) (121.29 cm)
D
Top Grille Filler
E
Top Grille Panel
48
³⁄₈" ¹⁄₈"
47¹⁄₄" 47³⁄₄"
(120.02 cm) (121.29 cm)
47¹⁄₄" 47³⁄₄"
(120.02 cm) (121.29 cm)

INSTALLATION INSTRUCTIONS

Unpack the Refrigerator

WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
IMPORTANT:
Do not remove the film covering until the refrigerator is in its
operating location.
All four leveling legs must contact the floor to support and
stabilize the full weight of the refrigerator.
Keep the cardboard shipping piece or plywood under the
refrigerator until it is installed in the operating location.
1. Remove and save the literature package and hardware kit
located inside the refrigerator. Remove and save the literature,
grille, and trim taped to the outside of the refrigerator.
NOTE: Do not remove tape and door bracing until the
refrigerator is in its final location.
