  • Page 1 2016 Rider’s Manual Victory Vision Tour...
  • Page 2 California Proposition 65 Warning This product contains or emits chemicals known to the state of California to cause cancer and birth defects or other reproductive harm.
  • Page 3 2016 Rider’s Manual ® Victory Vision Tour...
  • Page 4 All reference to RIGHT, LEFT, FRONT, REAR are from the operator’s perspective seated in a normal riding position. Features of VICTORY Motorcycles are covered by U.S. Patent Nos: 6,976,691; 6,407,663; D489670; D482311; D482304; D481980; D481973; D474142. The following are registered trademarks of Polaris Industries Inc.: ®...
  • Page 5 WARNING Improper vehicle use can result in SEVERE INJURY or DEATH. NEVER Operate: • If you are under the age of 16 and without a driver’s license with motorcycle endorsement • Under the influence of drugs or alcohol • Off-road •...

  • Page 7: Table Of Contents

    Table of Contents Introduction ......... 6 Safety .

  • Page 8: Introduction

    VICTORY dealer. To locate the nearest authorized VICTORY dealer, call 1-800-POLARIS or visit www.polaris.com. VICTORY motorcycles comply with all federal, state and local safety and emission regulations for the area of intended sale.

  • Page 9: Safety

    Safety About the Rider's Manual WARNING Failure to follow recommended precautions and procedures could result in severe injury or death. Always heed all safety precautions and follow all operation, inspection and maintenance procedures outlined in this manual. This rider’s manual contains information that is essential to safe riding and proper maintenance of your VICTORY motorcycle.

  • Page 10: Safe Riding Practices

    49. Failure to do so can result in serious engine damage. • Some VICTORY motorcycles include saddlebags, a windshield, a trunk, or a passenger backrest as standard equipment. To maintain stability, be prepared to reduce the operating...
  • Page 11 Safety Safe Riding Practices Follow these general safe riding practices: • Before each ride, perform the pre-ride inspections as outlined beginning on page 40. Failure to do so may result in damage to the motorcycle or an accident. • Until you're thoroughly familiar with the motorcycle and all of its controls, practice riding where there is little or no traffic.
  • Page 12 Safety Safe Riding Practices • Reduce speed when: • the road has potholes, or is otherwise rough or uneven. • the road contains sand, dirt, gravel or other loose substances. • the road is wet, icy or oily. • the road contains painted surfaces, manhole covers, metal grating, railway crossings or other slippery surfaces.
  • Page 13 Safety Safe Riding Practices Carrying a Passenger Do not carry a passenger unless the motorcycle is equipped with passenger seat and passenger footrests.. To carry a passenger safely: • Do not exceed the gross vehicle weight rating (GVWR) for your motorcycle. See the manufacturer’s label (on the left side of the frame at the steering head).

  • Page 14: Parking The Motorcycle

    Safety Use of Accessories Because VICTORY cannot test and make specific recommendations concerning every accessory or combination of accessories sold, the operator is responsible for determining that the motorcycle can be safely operated with any accessories or additional weight. Use the following guidelines when choosing and installing accessories: •...
  • Page 15 Safety Carrying Cargo Use the following guidelines when attaching cargo or accessories to the motorcycle. Where applicable, these guidelines also refer to the contents of any accessories. • Keep cargo and accessory weight to a minimum, and keep items as close to the motorcycle as possible to minimize a change in the motorcycle’s center of gravity.

  • Page 16: Transporting The Motorcycle

    Safety Transporting the Motorcycle If you must transport the motorcycle: To loop on frame (one tiedown each side) • Use a truck or trailer. Do not tow the motorcycle with another vehicle, as towing will impair the motorcycle's steering and handling. •...

  • Page 17: Electromagnetic Interference

    Safety Safety Maintenance WARNING Failure to perform safety maintenance as recommended can result in difficult handling and loss of control, which could result in serious injury or death. Always perform the safety maintenance procedures as recommended in this manual. Perform maintenance and repairs promptly as outlined in the VICTORY service manual, or see your authorized VICTORY dealer for service.
  • Page 18 Safety Gross Vehicle Weight Rating (GVWR) WARNING! Exceeding the gross vehicle weight rating of your motorcycle can reduce stability and handling and could cause loss of control. NEVER exceed the GVWR of your motorcycle. The maximum load capacity of your motorcycle is the maximum weight you may add to your motorcycle without exceeding the GVWR.

  • Page 19: Reporting Safety Defects

    Safety Safety and Information Labels Labels are model-specific and market-specific. Your motorcycle may not contain all of the labels shown. See page 85 for seat removal instructions. 1. Windshield Label 2. Vehicle Identification Number (VIN) (on frame, under rear console cover) 3.

  • Page 20: Identification / Component Location

    Identification Ignition Key Number Key Number The ignition key number is stamped on the small metal tag attached to the key ring. Remove the tag and record the number on page 113. Store the tag in a safe place. Additional keys can be copied from one of the original keys. A VICTORY key blank is required.

  • Page 21: Left Side View

    Identification Left Side View 1. Spark Plugs 2. Power Port 3. Front Brake Caliper 4. Gear Shift Pedal 5. Operator Footrest 6. Sidestand 7. Oil Drain Plug 8. Oil Filter 9. Passenger Footrest 10. Rear Brake Caliper 11. Diagnostic Connector (in saddlebag) 12.

  • Page 22: Top View

    Identification Top View 1. Windshield 2. Radio Antenna (under dash) 3. Mirror 4. Clutch Fluid Reservoir 5. Clutch Lever 6. Glove Compartment Door 7. Operator Seat 8. Passenger Seat 9. Saddlebag Latch 10. Trim Panel (if equipped) 11. Front Brake Lever 12.
  • Page 23 Identification Rear View 1. Turn Signals (uppermost in lens) 2. Tail Lamps (3 each side) 3. Brake Lamps 4. Exhaust Mufflers 5. License Plate Bracket Console 1. Speakers 2. Fuel Gauge 3. Speedometer 4. Indicator Lamp Display 5. Multi-Function Display 6.

  • Page 24: Instruments, Features & Controls

    Instruments, Features and Controls Ignition Switch Place the ignition key in the ignition switch to operate the following functions of the switch. All electrical circuits are off. The key can be removed. All electrical circuits are on. The ignition key cannot be removed. Headlamp, taillight, running lights, radio and instrument lights illuminate.

  • Page 25: Ignition Switch

    Instruments, Features and Controls Ignition Switch Fuel Fuel Door Lock Door 1. Turn the handlebars full left. Release 2. Turn the key to the OFF position. Tip: Do not push the key down when unlocking the fuel door. 3. Turn the ignition key counter-clockwise to release the fuel door latch.

  • Page 26: Instrument Cluster

    Instruments, Features and Controls Instrument Cluster The instrument cluster includes the speedometer, tachometer, fuel gauge, volt meter, indicator lamps and multi-function display. Indicator Lamps Tachometer Speedometer Volt Meter Fuel Gauge Multi-Function Display Speedometer The speedometer displays vehicle speed in either miles per hour or kilometers per hour. See page 27.
  • Page 27 Instruments, Features and Controls Indicator Lamps Anti-Lock Brake System (ABS) (if equipped) Right Turn High Beam Low Fuel Left Turn Oil Pressure Cruise Control Check Engine Battery Warning Neutral Lamp Indicates Condition Neutral This lamp illuminates when the transmission is in neutral and the ignition key is in the ON or ACC position.

  • Page 28: Indicator Lamps

    Instruments, Features and Controls Indicator Lamps Lamp Indicates Condition Low Fuel This lamp illuminates when approximately one gallon (3.8 liters) of fuel remains in the fuel tank. Low Battery This lamp illuminates when battery voltage is low. Make sure the Warning charging system is operating properly.
  • Page 29 Instruments, Features and Controls Multi-Function Display Engine Error Codes The error screen displays only when the CHECK Error Code Failure Mode ENGINE light is on or when it goes on and off Number (0-9) Indicator (FMI) during one ignition cycle. Error codes are not stored.
  • Page 30 Instruments, Features and Controls Multi-Function Display Clock Tip: The clock must be reset any time the battery has been disconnected or discharged. 1. Turn the key to ON or ACC. Use the mode button to toggle to the odometer display. Tip: If LOW FUEL is flashing, the display will not enter the CLOCK SET mode.

  • Page 31: Console Switches

    Instruments, Features and Controls Console Switches Optional Hand Grip Accessory Heater Switch Switch Hazard Switch Driving Lamp Switch Hand Grip Heater Switch High Press the top (high heat) or bottom (low heat) of the rocker switch to turn the hand grip heaters on. Move the switch to the center position to turn the heaters off.

  • Page 32: Tilt Sensor

    Instruments, Features and Controls Seat Heater Switches High Seat heater switches (if equipped) are located on the seat under the left passenger hand grip. The low heat setting is adequate for most conditions. Use the high heat setting with caution. •...

  • Page 33: Horn Switch

    Instruments, Features and Controls Headlamp Switch (High/Low) High Beam The headlamp switch is located on the left handlebar. Use the switch to toggle the headlamp to high beam or low beam. The key must be in the ON or ACC position. Beam Tip: To turn the headlamp on, turn the ignition key to ON and tap or press the start switch.

  • Page 34: Turn Signal Switch

    Instruments, Features and Controls Turn Signal Switch The turn signal switch is located on the left handlebar. Use the switch to activate a turn signal. The key must be in the ON or ACC position. • Push the switch to the left to activate the left turn signals. •...

  • Page 35: Engine Starter Switch

    Instruments, Features and Controls Engine Starter Switch The starter switch is located on the right handlebar. Use the starter switch to start the engine, turn the headlights on and operate in reverse (if equipped). The switch will operate only when the engine stop/run switch is in the RUN position and the transmission is in neutral (or the clutch is disengaged).

  • Page 36: Throttle Control Grip

    Instruments, Features and Controls Throttle Control Grip The throttle control grip is located on the Decrease right handlebar. Use the throttle control grip Speed to control engine speed. While seated in the proper riding position: • Rotate the top of the grip rearward to increase engine speed and power.
  • Page 37 Instruments, Features and Controls Brakes Anti-Lock Brake System (ABS) • Operating with non-recommended tires or improper tire pressure may reduce the effectiveness of the anti-lock brake system. Always use the recommended size and type of tires specified for your vehicle. Refer to the specification section beginning on page 113. Always maintain the recommended tire pressure.

  • Page 38: Gear Shift Pedal

    Instruments, Features and Controls Brakes Rear Brake Pedal The rear brake pedal is located on the right side of the motorcycle. Press downward on the rear brake pedal to apply the rear brake. The rear brake pedal activates the rear brake caliper fully while simultaneously activating one of the three pistons in each front brake caliper.

  • Page 39: Windshield Adjustment

    Instruments, Features and Controls Pedal Adjustment The brake pedal and gear shift pedal controls can be adjusted to a front, rear or center position. The center position is the factory setting. Tip: An accessory linkage rod is needed to fully adjust the gear shift pedal control.

  • Page 40: Glove Compartment

    Instruments, Features and Controls Glove Compartment Before opening the glove compartment, turn the handlebars slightly to the right. 1. Press and release the inner edge of the compartment door. The door will open under light spring tension. 2. To close the glove compartment door, press the inner edge of the door downward firmly to secure the latch.
  • Page 41 Instruments, Features and Controls Radio/Audio Systems Radio Panel Refer to the Audio System section of this manual (beginning on page 117) for radio and accessory audio systems operation. Tool Kit The tool kit can be used to perform most basic maintenance items. Tools provided in the tool kit include: 1.

  • Page 42: Pre-Ride Inspections

    Pre-Ride Inspections To keep your motorcycle in safe operating condition, always perform the recommended pre- ride inspections before each ride. This is especially important before making a long trip and when removing the motorcycle from storage. WARNING! Failure to perform the recommended pre-ride inspections could result in component failure while riding, which could result in serious injury or death.
  • Page 43 Pre-Ride Inspections Turn the ignition key to the ON position and move the stop/run switch to RUN before performing the following electrical inspections. Return the ignition key to the OFF position after completing these inspections. If inspection of any electrical item reveals component failure, repair or replace the component before operating the motorcycle.
  • Page 44 Pre-Ride Inspections Engine Oil Level Polaris recommends the use of only VICTORY Semi-Synthetic 20W-40 oil, Synthetic 15W- 60 oil or an equivalent oil designed for use with wet clutches (such as those with a JASO MA rating). The oil fill cap/dipstick is located on the right side of the vehicle.
  • Page 45 Pre-Ride Inspections Tires Tire Pressure Check tire pressure before riding, when the tires are cold. This will provide the most accurate reading, as riding warms the tires and increases tire air pressure. Adjust tire pressure as needed based on the total weight of your intended load. See page 79. Tire Condition Inspect the tire sidewalls, road contact surface and tread base.
  • Page 46 Pre-Ride Inspections Rear Brake Pedal 1. Press downward on the rear brake pedal. It should move freely and smoothly. It should not move more than 3/8 inch (8 mm) before resistance is firm. It should continue to feel firm, without loss of pressure, until the pedal is released.

  • Page 47: Brake Pads

    Pre-Ride Inspections Brake Lines Inspect all brake hoses and connections for dampness or stains from leaking or dried fluid. Tighten any leaking connections and replace components as necessary. Tip: Refer to the service manual or contact your dealer for fastener torque values. WARNING! Brake fluid leaks or low brake fluid levels could cause brake system failure, which could result in serious injury or death.

  • Page 48: Hydraulic Clutch

    Pre-Ride Inspections Hydraulic Clutch Minimum 1. Position the motorcycle on level ground in the fully Level upright position. Position the handlebars so that the clutch fluid reservoir is level. 2. View the fluid level through the sight glass. The fluid should be clear.
  • Page 49 Pre-Ride Inspections Front Suspension Inspect the front forks for oil leaks or damage, and verify smooth suspension operation. See page 70. Steering 1. On level ground, straddle the motorcycle and bring it to the fully upright position. Turn the handlebars from stop to stop. The action should be smooth, but not loose. 2.
  • Page 50 Pre-Ride Inspections Sidestand 1. On level ground, straddle the motorcycle and bring it to the fully upright position. 2. Move the sidestand up to the stored position and down to the fully extended position several times. It should move smoothly and quietly. Make sure the return spring holds the sidestand tightly in place when the sidestand is in the stored position.

  • Page 51: Operation

    Operation The operation section of this manual describes how to ensure maximum performance and longevity through the proper care and operation of your motorcycle. Tip: Even if you're an experienced motorcycle operator or passenger, read all of the safety information in this manual before operating the motorcycle.
  • Page 52 Operation Fueling Always refuel on level ground with the sidestand down. Review the fuel warnings. See page 14. Use only the recommended fuel. See page 113. Hold the nozzle while filling. Do not rest the weight of the nozzle and hose on the filler neck. Do not leave the nozzle unattended. WARNING! Overflows or spilled gasoline could contact a hot engine or exhaust system and cause a fire, which could result in serious injury or death.

  • Page 53: Starting The Engine

    Operation Starting the Engine The starter interlock system allows the engine to be started only when the transmission is in neutral, or when the transmission is in gear with the clutch disengaged (clutch lever pulled in). Tip: If the motorcycle runs out of fuel, prime the system before attempting to restart the engine. See page 50.

  • Page 54: Shifting Gears

    Operation Shifting Gears WARNING! Forced shifting (with clutch engaged) could cause damage to the engine, transmission and drive train. Such damage could cause loss of control, which could result in serious injury or death. Always pull the clutch lever fully toward the handlebars to disengage the clutch before shifting gears. This motorcycle is equipped with a six-speed Overdrive transmission.
  • Page 55 Operation Shifting Gears Recommended Shift Points Upshifting (Accelerating) Downshifting (Decelerating) Gear Change Recommended Speed Gear Change Recommended Speed 1 to 2 18 MPH (29 km/h) O/D to 5 50 MPH (80 km/h) 2 to 3 30 MPH (48 km/h) 5 to 4 35 MPH (56 km/h) 3 to 4 40 MPH (64 km/h)
  • Page 56 Operation Using Cruise Control If equipped, the cruise control is located on the right handlebar. Make sure you read this section and understand how to safely operate this feature before using the cruise control. Cruise Type R: Verify which type of cruise control is installed on your vehicle by checking for a label in the left saddlebag.
  • Page 57 Operation Using Cruise Control Resume Speed 1. Disengage the cruise control with the brake, throttle or clutch. 2. Press the resume button (RES) to return to the set speed. Resume (Type R: You must wait at least 3 seconds after disengaging cruise control before pressing resume.

  • Page 58: Stopping The Engine

    Operation Stopping the Engine Before stopping the engine, bring the motorcycle to a complete stop. Shift to neutral or disengage the clutch. WARNING! Stopping the engine with the transmission in gear while the motorcycle is moving could cause loss of rear wheel traction or engine and transmission damage, which could cause loss of control and serious injury or death.
  • Page 59 Operation Reverse Operation (if equipped) NOTICE: Do not attempt to engage or disengage the reverse system when the motorcycle is moving. Before Operating in Reverse: • always sit on the motorcycle with legs astride and both feet on the ground. •...

  • Page 60: Maintenance

    Maintenance Safety During Service Procedures WARNING Failure to follow recommended precautions and procedures could result in severe injury or death. Always heed all safety precautions and follow all operation, inspection and maintenance procedures outlined in this manual. • Improperly installed or adjusted components can make the motorcycle unstable or hard to handle. Improperly installed electrical components can cause engine or electrical system failure.

  • Page 61: Major Maintenance

    Maintenance Proper maintenance assures the highest level of safety, durability and dependability for your motorcycle. • Have your VICTORY dealer perform the break-in maintenance procedures when the motorcycle’s odometer registers 500 miles (800 km). • Perform the recommended periodic maintenance at the intervals specified in the periodic maintenance table beginning on page 60.
  • Page 62 Maintenance Periodic Maintenance Table See table key below Odometer Reading in Miles (Kilometers) Component Page Air Filter Battery Brake Fluid** Brake Pads Clutch Cable (Mechanical) Clutch Fluid Clutch Lever (Hydraulic) Clutch Lever 74, 75 (Mechanical) Control Cables 73, 75 Crankcase Vent Drive Belt Drive Belt Adjustment Adjust with each tire change thereafter...

  • Page 63: Maintenance Log

    Maintenance Maintenance Log Maintenance Performed Miles / Km Notes Performed...
  • Page 64 Maintenance Engine Oil / Filter Change Change the engine oil at the intervals specified in the periodic maintenance table beginning on page 60. 1. Start the engine and allow it to idle for several minutes. Stop the engine. Tip: The engine must be at normal operating temperature before changing the oil.

  • Page 65: Air Filter

    Maintenance Engine Oil / Filter Change 8. Start the engine and allow it to idle for several minutes. Stop the engine. NOTICE: After an oil change, the low oil pressure indicator remains illuminated longer than usual before going out. Revving the engine while the low oil pressure indicator is illuminated can damage the engine.

  • Page 66: Drive Belt Condition

    Maintenance Drive Belt Condition Replace the drive belt if it is cracked or has broken teeth or frayed edges. No matter its condition, the drive belt should be replaced at periodic intervals. See the VICTORY Service Manual or an authorized VICTORY dealer. DO NOT attempt to check belt tension if the belt has been exposed to rain or washing within a 24 hour period or if the belt is hot from riding.
  • Page 67 Maintenance Drive Belt Tension Data Specifications are listed below for deflection and sonic tension. Sonic tension measurement requires Gates Sonic Tension Meter 507C or an equivalent. Drive Belt Deflection (Using PV-43532 Tension Gauge) Deflection 32 mm ± 0.5 mm Drive Belt Sonic Tension (Using Sonic Tension Meter) Required Data Sonic Tension Span...
  • Page 68 Maintenance Drive Belt Tension Inspection 1. Elevate and support the motorcycle with the rear tire slightly off the floor. CAUTION! Make sure the motorcycle is stable when elevated. Injury may occur if the motorcycle tips or falls. 2. Place the transmission in neutral. Drive Belt 3.
  • Page 69 Maintenance Drive Belt Tension Adjustment 1. Move the wheel to the tight spot location determined previously. 2. Loosen the rear axle nut on the left side. 3. Turn each axle adjuster nut clockwise an equal amount to tighten the belt (reduce deflection) or an equal amount counter-clockwise to loosen the belt (increase deflection).

  • Page 70: Rear Suspension Adjustment

    Maintenance Rear Suspension Adjustment For riding comfort and to ensure proper ground clearance, adjust rear shock air pressure as specified on the label located in left saddlebag area (see below). Follow these guidelines when adjusting: • Park the motorcycle with the sidestand down on a firm, level surface.
  • Page 71 Maintenance Rear Suspension Adjustment 1. Park the motorcycle with the sidestand down Bleed on a firm, level surface. Remove all riders Button Fitting and cargo. 2. Open the left saddlebag door. Remove the cap from the air fitting. 3. Refer to the shock label to determine the recommended air pressure.
  • Page 72 Maintenance Swing Arm / Rear Axle Inspection 1. Sit in the operator's seat and slowly bounce the rear suspension a few times. Make sure the suspension moves freely without binding. Listen for abnormal noises. 2. Elevate and support the motorcycle with the rear tire slightly off the floor. CAUTION! Make sure the motorcycle is stable when elevated.

  • Page 73: Evaporative Emission Control System

    Maintenance Steering Head Inspection View 1. Elevate and support the motorcycle with the front tire slightly off the floor. CAUTION! Make sure the motorcycle is stable when elevated. Injury may occur if the motorcycle tips or falls. 2. Turn the handlebars from stop to stop. The action should be smooth but not loose.

  • Page 74: Throttle Control Inspection

    Maintenance Throttle Control Inspection 1. With the engine OFF, rotate the throttle control grip fully open and then release it. It should rotate smoothly from the rest position to the completely open position. It should return to the rest position quickly when released. 2.

  • Page 75: Throttle Cable Lubrication

    Maintenance Throttle Cable Lubrication Lubricate control cable ends at the intervals recommended in the periodic maintenance table beginning on page 60. NOTICE: External casings are factory-lubricated. Additional lubrication could be detrimental to cable performance. Verify proper routing and smooth movement. Inspect for damage to the external casing, and inspect exposed cable wire for fraying, kinks or corrosion.
  • Page 76 Maintenance Hydraulic Clutch Fluid 1. Straddle the motorcycle and bring it to the fully upright position. Position the handlebars so that the Minimum fluid reservoir is level. Level 2. Wipe the fluid container and the area around the reservoir cover with a clean cloth. 3.
  • Page 77 Maintenance Mechanical Clutch Lever Lubrication 1. Remove the right side access cover. Loosen the clutch Pivot Screw cable adjuster lock nut. 2. Turn the cable adjuster completely inward to provide maximum lever freeplay. 3. Remove the clutch lever pivot nut and screw. Disconnect the clutch cable from the clutch lever.

  • Page 78: Brake Fluid Precautions

    Maintenance Front Brake Lever 1. Lubricate the pivot bushing at the intervals recommended in the periodic maintenance table beginning on page 60. Also lubricate any time binding is evident. Use VICTORY All Purpose Grease or equivalent. 2. Inspect brake pads as outlined on page 45. Brake Lever Bushing Rear Brake Pedal 1.

  • Page 79: Rear Brake Fluid

    Maintenance Rear Brake Fluid Change the brake fluid at the intervals recommended in the periodic maintenance table beginning on page 60 or every two years, whichever comes first. 1. Position the motorcycle on level ground in the fully upright position. 2.

  • Page 80: Wheel Inspection

    Maintenance Brake Disc Inspection / Cleaning 1. Inspect brake pads as outlined on page 45. 2. Inspect brake discs for nicks, scratches, cracks or other damage. Inspect the thickness of each brake disc at four or more locations around the disc. If any disc is worn to the minimum thickness at the thinnest point, or if a disc is damaged, see your VICTORY dealer for replacement.
  • Page 81 Maintenance Tires WARNING Operating the motorcycle with improper tires or with improper or uneven tire pressure could cause loss of control or accident. Always use the correct size and type of tires specified for your vehicle. Always maintain proper tire pressure as recommended in the owner's manual and on safety labels. Tire Condition Inspect the tire sidewalls, road contact surface, and tread base for cuts, punctures, and cracking.

  • Page 82: Spark Plugs

    Maintenance Spark Plugs Replace spark plugs at the intervals recommended in the periodic maintenance table beginning on page 60. Always replace spark plugs in pairs. 031-.035 inch (0.8-0.9 mm) Spark Plug Specifications Spark Plug Type NGK DCPR6E Spark Plug Gap .031-.035 inch (0.8-0.9 mm) Spark Plug Torque 10.8-14.5 ft-lbs (14.6-19.7 Nm)
  • Page 83 Maintenance Battery The motorcycle battery is a sealed, maintenance-free battery. Do not remove the battery cap strip for any reason. Keep the battery connections clean and tight at all times. WARNING Battery electrolyte is poisonous. It contains sulfuric acid. Serious burns can result from contact with skin, eyes or clothing.

  • Page 84: Battery Removal

    Maintenance Battery Removal 1. Turn the handlebars full right. 2. Remove the five belly pan screws. Tool: 6 mm Allen wrench 3. Remove the screw that joins the two side grills. Tip: The grill screw is placed in the FRONT hole. The center belly pan screw uses the rear hole.

  • Page 85: Battery Installation

    Maintenance Battery Installation WARNING! Improperly connecting or disconnecting battery 85 in-lbs (10 Nm) cables can result in an explosion and cause serious injury or 36 in-lbs (4 Nm) death. When removing the battery, always disconnect the negative (black) cable first. When reinstalling the battery, always connect the negative (black) cable last.

  • Page 86: Sidestand Lubrication

    Maintenance Ignition Switch / Lock Lubrication Periodically lubricate the ignition switch and door locks. We recommend the use of VICTORY Multi-Purpose Lubricant. 1. Spray lubricant directly into the ignition switch and into each lock cylinder for 1-2 seconds. 2. Insert each key into its lock and turn it to all positions to distribute the lubricant. 3.

  • Page 87: Windshield Trim Panel Removal

    Maintenance Seat Removal / Installation 1. Open the glove compartment door and the fuel door. 2. Lift the console trim panel straight upward at each corner to remove it. Do not tip the panel rearward. 3. Remove the two seat bolts. Tool: 4 mm Allen wrench 4.
  • Page 88 Maintenance Street Trim Panel Removal 1. Remove the seat, license plate and bracket. See Tabs page 85. 2. Open the saddlebags. 3. Working from top to bottom, lift each edge of the tail molding to release the tabs. Lift the tail Trim molding just enough to provide clearance to Panel...

  • Page 89: Trunk Installation

    Maintenance Trunk Removal Wire Harness 1. Remove the seat. See page 85. 2. Disconnect the trunk wire harness. 3. Remove the license plate. 4. Remove the two 4 mm Allen screws from bottom of the license plate bracket. Remove the bracket.

  • Page 90: Headlamp Bulb Replacement

    Maintenance Headlamp Bulb Replacement 1. Remove the air filter. See page 63. 2. Pull the sealing boot away from the back of the bulbs and housing. 3. Press the looped end of the wire bulb retainer clip and swing the end toward the center of the bulb to release it from the latch tab.
  • Page 91 Maintenance Taillight / Brake Light / Turn Signal Bulb Replacement 1. Open the saddlebags. Screws Tip: Removal of the trunk or street panel is not necessary. 2. Remove the license plate and bracket. See page 85. 3. Working from top to bottom, lift each edge of the tail molding to release the tabs.

  • Page 92: Headlamp Aim Adjustment

    Maintenance Headlamp Aim Adjustment The high beam should shine straight forward. The low beam will spread more toward the right (U.S./Canada). 1. Verify that tire pressure is at specification. See 25 ft. (7.6 m) page 79. Verify that rear suspension ride height (preload) is at specification.

  • Page 93: Fuse Boxes

    Maintenance Fuse Boxes Remove the windshield trim panel to access the fuses, auto-reset circuit breakers and relays. See page 85. Use the fuse puller provided in the tool kit to remove a fuse. Left Fuse Box Right Fuse Box Fuse Replacement 1.

  • Page 94: Electrical Precautions

    Maintenance Electrical Precautions Be aware of the following “DO’s” and “DO NOT’s” regarding the electrical system to avoid disruption of electrical signals and possible system malfunction. • DO use ONLY genuine VICTORY parts and accessories designed for your model and follow the instructions provided.

  • Page 95: Road Test

    Maintenance Elevating the Motorcycle WARNING! Serious injury or death can occur if the motorcycle tips or falls. Make sure the motorcycle will not tip or fall while elevated or while on the sidestand. Some procedures require raising the motorcycle to remove weight from the component being inspected.

  • Page 96: Troubleshooting

    Maintenance Troubleshooting For your personal safety, do not attempt inspection or repairs not fully described in this rider’s manual. Contact an authorized VICTORY dealer for service if you cannot determine the cause of a problem or if the inspection / repair exceeds your mechanical ability or tool resources.
  • Page 97 Maintenance Troubleshooting Shifting Difficulties or Hard to Find Neutral Possible Cause Possible Remedy/Action Shift Linkage Bushings Dry Or Worn Lubricate shift linkage. Engine Oil Level Incorrect Or Wrong Type Inspect level and quality of oil. See page 42. Hydraulic Clutch Fluid Contaminated Flush hydraulic clutch fluid (see dealer).
  • Page 98 Maintenance Service Manual Availability Some procedures are beyond the scope of this manual. See your dealer to purchase a VICTORY Service Manual for your motorcycle. Some procedures provided in the Service Manual require specialized knowledge, equipment, and training. Be sure you have the required technical skills and tools that are needed before you attempt ANY service on your motorcycle.

  • Page 99: Cleaning And Storage

    Cleaning and Storage VICTORY Cleaning Products This section provides tips on the very best way to clean, polish and preserve every surface of your beautiful new VICTORY motorcycle. We recommend the use of our VICTORY cleaning and polishing products and accessories, which have been specially designed to offer the best care possible for your VICTORY motorcycle.
  • Page 100 Cleaning and Storage Windshield Care (if equipped) Clean the windshield with a soft cloth and plenty of warm water. Dry with a soft clean cloth. Remove minor scratches with a high-quality polishing compound designed for use on polycarbonate surfaces. NOTICE: Brake fluid and alcohol will permanently damage the windshield. Do not use glass cleaners, water or soil repellents, and petroleum or alcohol based cleaners on the windshield, as these products can damage the windshield.
  • Page 101 Cleaning and Storage Gloss Clear Coat Finish Care The Axalta Sports and Equipment Finish System was used to provide the original gloss finish on your motorcycle. This finish system provides superior protection against the elements. To maximize the benefits of this system, use the following guide to care for the gloss finish on your motorcycle.
  • Page 102 Cleaning and Storage Polished Aluminum Care When a VICTORY motorcycle is new, the polished aluminum wheels, hand levers and shifter shine like chrome. Ultraviolet (UV) rays and oxidation will cause polished aluminum to grow dull, however, if it’s not properly polished and protected. VICTORY Awesome Metal Polish will clean, polish and protect these aluminum surfaces.
  • Page 103 Cleaning and Storage Polishing the Motorcycle Premium Polishing for Long-Lasting Protection The premium method of polishing paint and chrome utilizes the latest in high-quality polymer technology that provides the longest-lasting protection available in the polish industry today. VICTORY Liquid Spray Wax for windshields, paint and chrome is formulated for polishing after washing and can be sprayed on wet or dry surfaces.

  • Page 104: Clean And Protect The Motorcycle

    Cleaning and Storage If you will not operate the motorcycle for several months, such as during the winter, store the motorcycle to prevent damage to the fuel system and the battery and to protect components from corrosion or deterioration. During storage you might use products that are potentially hazardous;...

  • Page 105: Engine Protection

    Cleaning and Storage Engine Protection Change the engine oil. See page 62. Carbon deposits and combustion acids, normally suspended in the engine oil when in service, settle on internal engine components during storage. Settled deposits can cause engine damage or internal corrosion. Battery Care 1.

  • Page 106: Removal From Storage

    Cleaning and Storage Removal From Storage 1. Remove the cover and unlock the front forks (if locked). 2. Verify that tire pressure is at specification. 3. Install the battery and perform an electrical inspection. 4. Check the oil level. If the motorcycle was stored in an area subject to wide swings in temperature and humidity (such as outdoors), change the engine oil before starting the engine.

  • Page 107: Warranty

    Victory Motorcycles Warranty Policy Limited Warranty Victory Motorcycles Division, Polaris Industries Inc., 2100 Highway 55, Medina, Minnesota 55340 gives a TWO YEAR LIMITED WARRANTY on all components of your VICTORY motorcycle against defects in material or workmanship. This warranty covers parts and labor charges for repair or replacement of defective parts and begins on the date of purchase by the original retail purchaser.
  • Page 108 LIMITED WARRANTY. ALL OTHER IMPLIED WARRANTIES (INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTY OF MERCHANTABILITY) ARE LIMITED IN DURATION TO THE ABOVE 24 MONTH WARRANTY PERIOD. VICTORY MOTORCYCLES DISCLAIMS ALL EXPRESS WARRANTIES NOT STATED IN THIS WARRANTY. SOME STATES DO NOT PERMIT THE EXCLUSION...
  • Page 109 In the country where your motorcycle was purchased: Warranty or Service Bulletin repairs must be done by an authorized VICTORY MOTORCYCLES dealer. If you move or are traveling within the country where your motorcycle was purchased, Warranty and Service Bulletin repairs may be requested from any authorized VICTORY MOTORCYCLES dealer.
  • Page 110 DEALER’S AUTHORIZED LOCATION. This policy does not apply to vehicles that have received authorization for export from VICTORY MOTORCYCLES. Dealers may not give authorization for export. You should consult an authorized dealer to determine this vehicle’s warranty or service coverage if you have any questions. This policy does not apply to vehicles registered to government officials or military personnel on assignment outside the country of the selling dealer’s authorized location.

  • Page 111: Motorcycle Noise Regulation

    Otherwise, the owner may become subject to penalties under state and local ordinances. Noise Emission Warranty VICTORY MOTORCYCLES warrants that this exhaust system, at the time of sale, meets all applicable U.S. EPA Federal noise standards. This warranty extends to the first person who buys this exhaust system for purposes other than resale, and to all subsequent buyers.
  • Page 112 Victory Motorcycle Division, Polaris Industries Inc. - Emission Control System Warranty Statement Your Warranty Rights and Obligations The California Air Resources Board and VICTORY MOTORCYCLES (hereinafter VICTORY) are pleased to explain the emission control system warranty on your 2014 or later VICTORY motorcycle. In California, new motor vehicles must be designed, built and equipped to meet the state’s stringent anti-smog standards.
  • Page 113 Warranties Emissions Control System Warranty I. Coverage Warranty defects shall be remedied during customary business hours at any authorized VICTORY dealer located within the United States of America in compliance with the Clean Air Act and applicable regulations of the United States Environmental Protection Agency and the California Air Resources Board.
  • Page 114 Such maintenance may be performed at a service establishment or by any individual. The warranty period begins on the date the motorcycle is delivered to an ultimate purchaser. VICTORY MOTORCYCLES 2100 Highway 55 Medina, MN 55340...

  • Page 115: Specifications

    Specifications Fuel Recommendation For best performance, use only unleaded gasoline with a 91 pump octane minimum (R+M/2 Method). DO NOT USE E-85 GASOLINE OR GASOLINE CONTAINING METHANOL. Using E85 or gasoline / methanol blends can result in poor starting and driveability, and may damage critical fuel system components.
  • Page 116 Specifications Vision Tour Dimensions (Dimensions and specifications may vary with features, options and accessories) Overall Length 106.4 in. (270.2 cm) Overall Width 44.8 in. (113.9 cm) Overall Height 56.3 in. (143.1 cm) Seat Height 26.5 in. (67.3 cm) Wheel Base 65.7 in.
  • Page 117 Specifications Vision Tour Capacities Engine Oil 5 qts. (4.73 l) Approximately 4.5 qts. (4.25 l) at oil change Fuel 6.0 gallons (22.7 l) Fuel Reserve 1.0 gallon (3.8 l) Engine Engine Type ® VICTORY Freedom 106 / 6 V-Twin Configuration 50°...
  • Page 118 Specifications Vision Tour Wheels And Tires Front Wheel Type / Size Cast 18 x 3.0 inch Front Tire Type / Size DUNLOP D418F Elite 3 - 130/70R18 63H Radial Rear Wheel Type / Size Cast 16 x 5.0 inch Rear Tire Type / Size...

  • Page 119: Audio

    Audio System Overview Audio System Introduction Not all motorcycles are equipped with all components discussed in the audio section of this manual. Components not installed at the factory can be purchased from and installed by your local VICTORY dealer. Software Updates Radio system software should be updated annually to ensure the best performance.

  • Page 120: Audio Controls

    Audio System Overview Main User Interface Audio Controls U.S.A. Sources Operation of the left handlebar audio controls is outlined in greater detail on the • FM • AM following pages. • WX • AUX (NAV MP3, AUX or iPod) • SiriusXM Radio European Sources •...
  • Page 121 Audio System Overview Citizens Band (CB) Radio Audio System Power Controls The ignition key must be in the ACC or ON position to use the audio system. If equipped, the operator’s CB radio controls are located on the left handlebar With the key in the ACC or ON position and above the audio controls.

  • Page 122: Operation

    Audio System Operation Audio Volume Control Selecting Audio Sources The driver can adjust volume for the front Press and release S/E or SRC until the and rear speakers, turn the speakers off or desired source is active. on and mute the system audio. Audio Mute Press and release MUTE to drop audio...
  • Page 123 Audio System Operation Selecting Audio Sources Audio Tuning NAV MP3 source active: Use the tuner on the left control to select U.S. / European models radio stations. Press and release ICOM NAV MP3 TUNE (+) or TUNE CB19 (-) to locate stations in single-step increments.
  • Page 124 Audio System Operation Audio Mode Menus Entering Mode Menus Fader Setting Press and release the MODE Press (+) or (-) on FADER button on the console panel to the console panel enter the audio system mode to change settings. menus. Continue to press and External release the MODE button EXTERNAL SPKRS...
  • Page 125 Audio System Operation Audio Mode Menus CB Headset Volume Controls (if equipped) The headsets have three separate volume settings: Intercom (ICOM) volume, CB receive volume and entertainment (ENT) volume. Always position headsets with the speakers directly over your ears to ensure the best sound quality and volume. Tip: The driver can turn off the external speakers and listen to audio only through the headsets.
  • Page 126 Audio System Operation Audio Mode Menus To change mode settings, enter the mode menu. Press (+) or (-) on the console panel to change settings. Press S/E to save and exit. Tip: Sources and menu options will be displayed only for installed components. ICOM Volume AUX Mode Press (+) or (-) on...
  • Page 127 Audio System Operation Audio Mode Menus Weather Band (WX) Weather band channels are broadcast by the To change mode settings, enter the mode National Oceanic and Atmospheric menu. Press (+) or (-) on the console panel Administration (NOAA). NOAA operates to change settings.

  • Page 128: Cb Radio - Icom

    CB Radio / ICOM System CB/ICOM Introduction CB Channels In the U.S.A., refer to the Federal When the CB radio system is active, “CB” Communications Commission (FCC) Plain and the active channel will display. Rules pamphlet accompanying this rider’s manual for a comprehensive guide of citizens band (CB) radio rules and ICOM 100.5...
  • Page 129 CB Radio / ICOM System Push-to-Talk (PTT) Squelch Press and hold the Squelch blocks top or bottom of the undesired signals and PTT button to noise by allowing the transmit over CB reception of signals radio. The passenger only over a specified must push and hold level.
  • Page 130 CB Radio / ICOM System Local/Distant CB Radio Mode To change mode Distant: Use this setting for weaker signals. CB LO / DX MODE settings, enter the Receiver sensitivity will be increased. Static DISTANT mode menu. Press and noise levels are increased. (+) or (-) on the Local: Use this setting for stronger signals CB LO / DX MODE...

  • Page 131: Headset Receptacles

    CB Radio / ICOM System ICOM System VOX Break Setting Driver ICOM Volume To change Push COM or ICOM or (+) or (-) on the ICOM VOL 15 settings, enter the console panel to adjust the sensitivity mode menu. Press setting.

  • Page 132: Aux - Ipod

    AUX / iPod Input Cable Setup The AUX and iPod input cables are To change an input cable: connected to the audio system through a 1. Open the left console storage bin. small hole in the left console storage bin. 2.
  • Page 133 AUX / iPod Getting Started The ignition key must be in the ACC or ON When iPod is active, the console screen will position to use the audio system. display “iPod” as the active source and iPod information in the display screen. Tip: To prevent battery drain, do not leave the key in the ACC position for long periods.

  • Page 134: Ipod Playlists

    AUX / iPod iPod Playlists iPod Tuning Press TUNE (+) or TUNE (-) once to move Access the iPod’s main music library and one track forward or backward. Press the user-defined playlists with the console button twice (double click) to bring up the preset buttons.

  • Page 135: Siriusxm Radio

    SiriusXM Radio About SiriusXM Satellite Radio A Warning Against Reverse Engineering for U.S.A. and Canadian Products) It is prohibited to copy, decompile, SiriusXM Radio offers an extraordinary disassemble, reverse engineer, hack, variety of commercial-free music, plus manipulate or otherwise make available any premier sports, news, talk radio, stand-up technology incorporated in receivers comedy, children’s and entertainment...
  • Page 136 SiriusXM Radio Getting Started SiriusXM Radio Reception The ignition key must be in the ACC or ON position to use the audio system. If the SiriusXM radio system is not Tip: To prevent battery drain, do not leave the receiving a signal due to being indoors (or key in the ACC position for long periods.
  • Page 137 SiriusXM Radio SiriusXM Radio Settings SiriusXM Radio Categories To access the menus, turn the audio system With SiriusXM as the active source, use the power on and change the active source to MODE button on the console to scroll to the SiriusXM Radio.

  • Page 138: Nav Mp3

    NAV MP3 Navigation MP3 Introduction Please read this manual and the GARMIN ZUMO 660 NAV MP3 information provided with your player to become familiar with all unit features and operation. The audio integration kit must be installed to enable outputs from the NAV MP3 (such as navigation instructions or user-loaded MP3 media files) to play through the headsets or speakers.

  • Page 139: Index

    Index About the Rider’s Manual....7 Cargo Distribution ......13 ABS.
  • Page 140 Index Engine Starter Switch ..... 33 Identification Number Record ....113 Engine Stop/Run Switch .

  • Page 141: Battery

    Index NAV/MP3 Mode, Changing ....136 Sidestand....... . 38 Navigation MP3 .
  • Page 142 Index Tachometer ......24 VICTORY Cleaning Products ....97 Taillight Bulb Replacement.
  • Page 143 To locate your nearest dealer, call 1-877-737-7172 or visit www.victorymotorcycles.com Victory Motorcycles 2100 Highway 55 Medina, MN 55340 Part No. 9926253 Rev 01 Printed in USA...

Table of Contents

Save PDF
