OTHER SETTINGS SCREEN

To update the device firmware, select the new firmware file. After having pressed the Upload

button, a dialog window will appear. Confirm the firmware update and wait for the process to

complete. Information on DSP1, DSP2 and WEB is also found in this section.

Information about the device storage space is found in this section. The internal storage could

be deleted by pressing the 'Format' button.

By pressing the 'Clear' button, all recorded in the system log information will be deleted.

All except IP – all settings except for the Network settings (IP Address) will be deleted;

To restore DB7000 to its Factory Defaults you should first select the desired option and then

press the relevant button. A new window will appear - confirm that you want to restore the factory

defaults and wait for the process to be completed. On completion of the process, the settings

should have the proper default values.

To start Rebooting of DB7000, press the Reboot button. A dialog warning window will appear.

Confirm that you want to reboot the device and wait for the process to be completed.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com

- 66 -
